Запчасти Case IH 700 (39.110.01) - HITCH, JACK/HOSE HOLDER (39) - FRAMES AND BALLASTING

1

88557

BOLT,Hex, 3/4" - 10 x 2", Gr 5, Full Thd

1шт.

2

280286

NUT,1"-8, GB

2шт.

3

88902

NUT,3/8"-16

6шт.

4

84128

BOLT,Hex, 1" x 3", Gr 5

2шт.

5

280375

NUT,3/4"-10, GC

1шт.

6

86609684

NUT,1 1/4"-7, GB

1шт.

7

6669

WASHER,1.06" ID x 1.75" OD x 0.13" Thk

2шт.

8

87552232

BOLT,Hex, 1 1/4" - 7 x 7 1/2", Gr 5

1шт.

9

7972

JACK

3000 lb x 15" long

1шт.

Refer to 39.110.03

1шт.

10

GR-457A

CHAIN (AG)

assembly, safety 60,600 lb

1шт.

11

434-640

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 2 1/2", Gr 5

4шт.

12

280661

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2", Gr 5

2шт.

13

87503801

CAUTION DECAL

negative hitch weight

2шт.

13

87712265

DECAL

Caution Negative Hitch Weight, Russian

2шт.

13

87551822

CAUTION DECAL

negative hitch weight - French

2шт.

14

87503802

DECAL

fold zone stay clear

2шт.

14

87712266

DECAL

Fold Zone Stay Clear, Russian

2шт.

14

87551823

DECAL

fold zone stay clear - French

2шт.

15

87503829

DECAL

rollover hazard

1шт.

15

87712267

DECAL

Rollover Hazard, Russian

1шт.

15

87551824

DECAL

rollover hazard - French

1шт.

16

GD-500.77

CAUTION DECAL

hydraulics

1шт.

16

GD-500.77RU

CAUTION DECAL

hydraulics Russian

1шт.

16

425206A1

CAUTION DECAL

hydraulics French

1шт.

17

87503842

CARRIER

hydraulic hose

1шт.

18

87506220

HITCH

hitch

1шт.

18

84471082

HITCH

CAT 4,5, Not Shown

1шт.

19

GL-813

CLAMP

hydraulic hose

2шт.

20

CC-106

HOSE CLAMP

for 4 hoses

2шт.

21

87342

LOCK WASHER,25.48mm ID x 42.06mm OD x 6.35mm Thk

2шт.

22

182270A1

WARNING DECAL

Do Not Ride

1шт.

23

86511609

NUT,1"-8, G8

2шт.

24

87020629

BOLT,Hex, 1" - 8 x 8 1/2", Gr 8

2шт.

25

87503838

BRACKET

hydraulic hose carrier

1шт.

26

256147A1

DECAL

read operator manual

1шт.
