Запчасти Case IH 6200 (9-178) - HYDRAULIC HOSE SUPPORT (09) - CHASSIS/ATTACHMENTS

1

515031R11

SPRING

ASSEMBLY - hose support

1шт.

2

SA1378A

PLUG

- spring

2шт.

113-604

BOLT,Hex, 5/8" - 11 x 2", Gr 5

1шт.

192-25

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

3

515028R1

ROD

- hydraulic hose support

1шт.

432-1216

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

1шт.

4

515029R1

BRACKET

- hose clamp

2шт.

5

515030R1

CLAMP

- hose

4шт.

598811R1

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5

BOLT - round head square neck, 3/8 NC x 1-3/4 inch

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

126032

WING NUT,3/8"-16

NUT - wing, 3/8 inch

2шт.

11

524671R1

DRUM

BAND - 8-3/4 inch diameter depth (For 2-3/4 inch penetration)

1шт.

11

493540R2

DRUM

BAND - 10-1/2 inch diameter depth (For 1-3/4 inch penetration)

1шт.

11

542555R2

DRUM

BAND - 11 inch diameter depth (For 1-1/2 inch penetration)

1шт.

11

461915R1

DRUM

BAND - 11-3/8 indh diameter depth (For 1-1/4 inch pernetration)

1шт.

11

524670R1

DRUM

BAND - 9-7/8 inch diameter depth (For 2 inch penetration)

1шт.

12

525820R1

SPACER,3/8" Pipe x .469"

- depth band

2шт.

598804R1

CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5

BOLT - round head square neck, 5/16 NC x 1-1/4 inch, depth band

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, , Depth band 5/16"

2шт.

619855R1

WASHER

- flat, 11/32 x 3/4 x 3/64 inch, depth band

2шт.

120376

NUT,5/16"-18, G5

Depth band 5/16"-18, G5

2шт.
