Запчасти Case IH 620 (A-66) - HYDRAULIC CYLINDER MOUNTING PARTS

Схема запчастей Case IH 620 - (A-66) - HYDRAULIC CYLINDER MOUNTING PARTS
4
1
2
5
3
3
6
7

Артикул

Название

Примечание

Количество

1

BRACKET, cylinder mounting, for service order 1, 819247C1, bracket, 1, 819248C1, bar, 2, 819262C1, bar, 2, 819383C1, retainer, 1, H2808, pin, 1, 103407, pin, 2, 271724, bolt, 2, 124589, nut and 2, 121574, washer, machines, Serial Range: prior-1975

1шт.

2

815561C1

ARM

RETAINER, cylinder, machines, Serial Range: prior-1975

1шт.

N32142

HEADED PIN,9.53mm OD x 53.98mm L

PIN, 3/8 x 2-1/8 std-hd-dld

1шт.

103384

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

1шт.

3

819262C2

LEDGER PLATE

BAR, mounting bracket tie, machines built 1975 & since

2шт.

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

5/8-11 x 2-1/4 hex-hd

2шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 hex.

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

4

819247C1

BRACKET

cylinder mounting machines built 1975 & since

1шт.

180177

BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5

1/2-13 x 1-1/2 hex-hd

2шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

2шт.

120384

WASHER,1/2"

LOCK, 1/2"

2шт.

5

819248C1

BAR

cylinder mounting machines built 1975 & since

1шт.

6

819383C1

RETAINER

cylinder machines built 1975 & since

2шт.

H2808

HEADED PIN,5/8" x 2"

PIN, 5/8 x 2 std-hd-dld

1шт.

432-1216

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

1шт.

7

651793R2

SUPPORT

ROD, hose support

1шт.

271723

SNAP RING,Hex, 5/8" - 11 x 2", Gr 5

5/8-11 x 2 hex-hd

1шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 hex.

1шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

464623R1

WASHER

21/32 x 1-1/2 x 11 ga

2шт.

Выбрано товаров: 21
