Запчасти Case IH 5500 (9-40) - DOUBLE DISC FURROW OPENER, MULCH TILL (MIN-TILL), ROTARY SCRAPER (09) - CHASSIS

Схема запчастей Case IH 5500 - (9-40) - DOUBLE DISC FURROW OPENER, MULCH TILL (MIN-TILL), ROTARY SCRAPER (09) - CHASSIS
38
15
34
43
49
11
10
33
42
56
11
12
2
18
37
35
44
50
13
7
28
25
27
39
17
53
51
4
47
31
48
21
3
1
6
15
19
47
17
41
6
20
14
36
32
8
29
5
16
40
12
55
27
24
35
13
57
5
4
30
22
52
54
45
16
46
9
3
7
14
8
26

Артикул

Название

Примечание

Количество

1

1334190C1

DRAWBAR

long 437.5mm tube length

1шт.

2

1334176C1

DRAWBAR

short 298.5mm tube length

1шт.

3

1969063C1

BAR

flat pressure 5/16" thick

2шт.

4

87872

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

2шт.

5

80681

LOCK WASHER,5/16"

2шт.

6

9635082

NUT,5/16" - 18, Gr 5

2шт.

7

113976A1

SPRING

C .162" wire .992" ID 1.34" OD and .816" ID 1.14OD 15.87" long

2шт.

8

1337321C1

CLIP

spring lock 1/4" OD

2шт.

9

439-5666

HEADED PIN,9.53mm OD x 104.78mm L

1шт.

10

439-5616

HEADED PIN,3/8" x 1"

1шт.

11

80756

COTTER PIN,1/8" x 3/4"

2шт.

12

1978922C1

BAR

3/16" tk with holes

2шт.

13

814812C1

SPACER

spring tooth

2шт.

14

1263794C1

SPACER

13.87MM ID x 21.34MM OD x 63.5MM long

2шт.

15

87996

BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 5

2шт.

16

80679

LOCK WASHER,1/20.507 CST ZND

2шт.

17

280431

NUT,1/2"-13, G5

2шт.

18

90850C92

DISC

OPENER ASSY, 14" STD LEADING, Includes disc, bearing and rivets

1шт.

18

90851C92

DISC

Assembly, 14" Trailing, Includes disc, bearing and rivets

1шт.

18

90409C1

FLANGED BEARING,34.95 mm ID x 45.187 mm OD x 24.63 mm

bearing retainer

1шт.

19

1268017C91

BALL BEARING,15.9mm ID x 45.23mm OD x 18.67mm W

ball 1.78 x .73 x .62 id

1шт.

19

1268017C91GV

BEARING

Value, Ball Bearing

1шт.

20

1337971C1

DISC

355.6 mm x 3.5 mm 6-hole opener/square

1шт.

21

86624111

RIVET,6.35mm OD x 14.29mm L

6шт.

21

86624111

RIVET,6.35mm OD x 14.29mm L

6шт.

22

324180A1

BEARING CAP,35.2 mm OD x 7.62 mm

bearing

2шт.

23

1978957C1

BOLT,Hex, 5/8" - 11 x 1-1/4", LH Thd, Gr 5

LK .625X1.25 UNC LH GR5 PLAIN, C/W .5 LOC-GRIP

1шт.

24

106-91020

LOCK BOLT,Locking, 5/8"-11 x 1 1/4", G5, Full Thd

1шт.

25

1268381C1

WASHER,16.66mm ID x 25.4mm OD x 0.05mm Thk

21/32" id x 1" od x .054 hardened

2шт.

26

1279970C2

BOOT

plastic inj molded black f/o front

1шт.

27

281-14816

SELF-TAP SCREW,HWH, 5/16" - 18 x 1"

3шт.

28

86624143

WASHER,0.34" ID x 1" OD x 0.12" Thk

1шт.

29

88893C1

PLATE

boot back-up

1шт.

30

842894C1

BOOT

rear, akulon

1шт.

31

842891C1

BOOT

FRONT FURROW OPENER

1шт.

32

1547038C1

PIN

FURROW OPENER

1шт.

33

129164

SNAP RING,#75, Ext

2шт.

34

1546975C1

SUPPORT

OPENER BOOT

1шт.

35

281-14816

SELF-TAP SCREW,HWH, 5/16" - 18 x 1"

3шт.

36

100495A1

BAR

bracket scraper mounting

1шт.

37

843364C92

KIT

scraper assembly - disk, inside

1шт.

37

816666C1

BLADE

Scraper, RH

1шт.

38

816665C1

BLADE

Scraper, LH

1шт.

39

816668C1

LEDGER PLATE

scraper

1шт.

40

819808C1

HINGE

inside scraper

1шт.

41

N62536

VALVE SPRING

C 1/16" wire x 15/32" od x 1" long

1шт.

42

433-544

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 2 3/4", Gr 5

1шт.

43

280736

NUT,5/16"-18, GC

1шт.

44

97756C1

BACK PLATE

scraper

1шт.

45

100641A1

PACKAGE

rotary scraper

1шт.

45

101533A1

SCRAPER

WHEEL, 4 INCH ROTARY

1шт.

46

101534A1

SCRAPER

WHEEL, 3-1/4 INCH ROTARY

1шт.

47

432-416

COTTER PIN,1/16" x 1"

2шт.

48

NSS

NOT SOLD SEPARAT

BRACKET, Mounting

1шт.

49

NSS

NOT SOLD SEPARAT

BRACKET, Scraper Side

2шт.

50

NSS

NOT SOLD SEPARAT

SPRING

1шт.

51

280497

CARRIAGE BOLT,Short Sq Nk, 5/16" - 18 x 3/4", Gr 5, Full Thd

1шт.

52

281010

LOCK NUT,7/8"-14, GC

1шт.

53

101458A2

PLASTIC-RUBBER TUBE,20.6,38 mm Length

grain rubber

1шт.

54

106781A1

CLAMP,35.7mm - 41.3mm

hose, nylon 1.41-1.63" id

1шт.

55

842892C2

ADAPTER

furrow opener

1шт.

56

842893C2

PLASTIC-RUBBER TUBE,42 mm OD x 219 mm L

rubber, seed, furrow opener

1шт.

57

819373C1

PACKAGE

DOUBLE DISK OUTSIDE SCRAPER

1шт.

Выбрано товаров: 63
