Запчасти Case IH 5300 (9-110) - BROME SEED ATTACHMENT, HIGH FRONT MOUNTED DRIVE (09) - CHASSIS

1

815671C11

GUARD

chain assembly

1шт.

2

598055R1

DRIVE BUSHING

3/4"id x 15/16"od

2шт.

3

9627874

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5, Full Thd

4шт.

4

413-514

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5

2шт.

5

80681

LOCK WASHER,5/16"

6шт.

6

9635082

NUT,5/16" - 18, Gr 5

6шт.

7

819023C1

COLLAR

clutch

1шт.

8

438-31624

PIN,6.35mm OD x 38.1mm L, Coiled

1шт.

9

603265R1

WASHER

2" id x 3 1/8" od x 14 ga

1шт.

10

603133R1

CAM

throwout

1шт.

11

80719

LUBE NIPPLE,1/8" NPT

1шт.

12

495-81026

WASHER,21/32" x 1 1/2" x .060"

1шт.

13

87395

COTTER PIN,1/8" OD x 1-1/4" OAL

1шт.

14

819025C1

CAM

clutch fixed

1шт.

15

819024C1

DRIVE SPROCKET

clutch 10 tooth

1шт.

16

35AC

SPRING

C .162 wire 1.89 OD 2.75

1шт.

18

818093C1

COLLAR

clutch spring

1шт.

19

438-31624

PIN,6.35mm OD x 38.1mm L, Coiled

1шт.

20

819305C1

LINKAGE

clutch shifter connecting

1шт.

21

1978737C1

COTTER PIN,Int, 1/8" x 49mm

3 mm x 49 mm

1шт.

22

603132R1

ARMATURE

shift rod arm

1шт.

23

280631

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 2 1/4", Gr 5

1шт.

24

495-61041

WASHER,10.31mm ID x 25.4mm OD x 1.6mm Thk

1шт.

25

80681

LOCK WASHER,5/16"

1шт.

26

9635082

NUT,5/16" - 18, Gr 5

1шт.

27

86624079

HEADED PIN,3/8" x 1 1/4", G2

1шт.

28

818097C2

ANGLE

clutch lockout

1шт.

29

86500692

BOLT,Hex, 3/8" - 16 x 3/4", Gr 8, Full Thd

1шт.

30

80680

LOCK WASHER,3/8 0.381 CST ZND

1шт.

31

9628503

NUT,3/8"-16, G5

1шт.

32

NSS

NOT SOLD SEPARAT

CHAIN ASSEMBLY - BROME SEED DRIVE

1шт.

Use 82 links of no. 25 steel chain

1шт.

33

818095C1

SUPPORT

plate LH

1шт.

33

818096C1

SUPPORT

plate RH

1шт.

34

818094C1

STUD

1/2"-13 x 5 3/8"

2шт.

35

280431

NUT,1/2"-13, G5

8шт.

36

80679

LOCK WASHER,1/20.507 CST ZND

4шт.

37

495-81287

WASHER,13.49mm ID x 31.75mm OD x 3.4mm Thk

4шт.

38

815645C11

SPROCKET

6 tooth #25 chain

2шт.

39

NSS

NOT SOLD SEPARAT

BUSHING Sprocket

1шт.

40

603735R1

DRIVEN SPROCKET

7T sq bore

1шт.
