Запчасти Case IH 5100 (144) - DISC MARKER, MANUAL, ROPE TYPE

1

815734C1

PIVOT

- disc marker front

1шт.

113-103

BOLT,Hex, 5/16" - 18 x 1", Gr 5

2шт.

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

2шт.

20893R1

WASHER

- flat, 11/32x 1 x 7/64 inch

1шт.

120376

NUT,5/16"-18, G5

2шт.

132-349

COTTER PIN,1/4" x 1 1/2"

PIN, Split (Cotter), 1/4" x 1-1/2"

1шт.

21753R1

WASHER

- flat, 25/32 x 1-1/2 x 3/64 inch

1шт.

2

815735C1

PIVOT

- disc marker rear

1шт.

598803R1

CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5, Full Thd

BOLT - round head square neck, 5/16 NC x 1 inch

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

120376

NUT,5/16"-18, G5

2шт.

132-349

COTTER PIN,1/4" x 1 1/2"

PIN, Split (Cotter), 1/4" x 1-1/2"

1шт.

21753R1

WASHER

- flat, 25/32 x 1-1/2 x 3/64 inch

1шт.

3

815739C1

BRACKET

BRACE - marker support

1шт.

4

815742C1

TUBE,1.775" ID, 2" OD, 26, 2.5" Length

- marker disc

1шт.

5

596516R11

TUBE,1767.8, 33 mm Length

- marker disc telescoping

1шт.

6

596521R2

BOLT,U, 5/16" - 24 x 3 3/4"

U-BOLT - marker disc tube

1шт.

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

2шт.

120368

NUT,5/16"-24, G5

2шт.

7

816581C1

BAR

- U-bolt clamping

1шт.

8

602992R1

GASKET

- bearing retainer

2шт.

9

602989R1

FLANGE,1.41" ID x 3.25" OD x 0.63"

- bearing

1шт.

104081

RIVET,But Hd, 1/4" x 1/2"

- 1/4 x 1/2 inch

6шт.

10

815893C1

ROD

- disc marker hold-up

1шт.

11

603004R2

PLOW DISC

DISC - marker

1шт.

12

602994R1

FLANGE

- disc, dirt seal

1шт.

13

465004R91

BEARING ASSY,0.6693" ID x 1.5748" OD x 0.4724"

ASSEMBLY - disc

1шт.

14

602987R1

BOLT

BOLT - disc marker

1шт.

-

192-25

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

121358

YOKE

- hex, 5/8 inch NF

1шт.

15

602990R1

CAP

- disc marker

1шт.

16

464628R1

SEAL

- disc marker, dirt (Replaces 602993R1)

1шт.

17

602988R1

SPACER

- dirt seal retainer

1шт.

18

591714R1

WASHER

- flat, 23/32 x 1-1/4 x 3/64 inch

1шт.

19

21712R1

WASHER

- flat, 23/32 x 1-1/2 x 3/32 inch

1шт.

20

815747C1

BAR

SUPPORT - disc marker rope mast

1шт.

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

21шт.

21309R1

WASHER

- flat, 13/32 x 7/8 x 11/64 inch

2шт.

120377

NUT,3/8" - 16, Gr 5

2шт.
