(79.904.AA[04]) - AIR DISTRIBUTION HOSE SUPPORT TOW BEHIND 40 FOOT

Запчасти Case IH 500 (79.904.AA[04]) - AIR DISTRIBUTION HOSE SUPPORT TOW BEHIND 40 FOOT (79) - PLANTING

Схема запчастей Case IH 500 - (79.904.AA[04]) - AIR DISTRIBUTION HOSE SUPPORT TOW BEHIND 40 FOOT (79) - PLANTING
4
3
2
3
home
4
3
4
4
1
2
3
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84566647

MANIFOLD

Primary Hose

2шт.

2

439409A1

U-BOLT

.75 6.16W 12D

2шт.

3

87326958

WASHER,0.78" ID x 1.25" OD x 0.05" Thk

.75ID 1.25 OD

4шт.

4

280375

NUT,3/4"-10, GC

4шт.

Выбрано товаров: 4
