Запчасти Case IH 400 (75.200.07) - END MARKER SINGLE MARKER HYDRAULICS (75) - SOIL PREPARATION

1

435414A1

QUICK MALE COUPLING,1/2"-14 NPTF

1шт.

2

221-89

REDUCER,Hex, 1/2" x 3/8" NPT

1шт.

3

6723

HYDRAULIC HOSE,0.25" ID x 240.00", SAE 100R17 Class 2 Type 2, SAE J517, SAE J516

1/4" x 240" fl

1шт.

27', 33' and 39' models

1шт.

3

432611A1

HYDRAULIC HOSE,0.25" ID x 288.00"

1/4" x 288" fl, 3/8" mpt x 3/8" mpt

1шт.

45', 51' and 57' models

1шт.

4

6917

HYDRAULIC HOSE

1/4" x 264" fl

1шт.

27' models

1шт.

4

432611A1

HYDRAULIC HOSE,0.25" ID x 288.00"

1/4" x 288" fl, 3/8" mpt x 3/8" mpt

1шт.

33' models

1шт.

4

6723

HYDRAULIC HOSE,0.25" ID x 240.00", SAE 100R17 Class 2 Type 2, SAE J517, SAE J516

1/4" x 240" fl

1шт.

39' models

1шт.

4

6919

HYDRAULIC HOSE,0.25" ID x 360.00", SAE 100R17 Class 2 Type 2, SAE J517, SAE J516

1/4" x 360" fl

1шт.

45' models

1шт.

4

6920

HYDRAULIC HOSE,6.35 mm ID x 10363.20 mm, SAE 100R17 Class 2 Type 2

1/4" x 408" fl

1шт.

51' models

1шт.

4

7049

HYDRAULIC HOSE,0.25" ID x 432.00", SAE J517, SAE J516, SAE 100R17

1/4" x 432" fl

1шт.

57' models

1шт.

5

87500855

HYDRAULIC CYLINDER,Double Acting, 28.57mm Rod, 304.8mm Stroke

2" x 12" Monarch 2500 psi without pins

1шт.

Refer to 75.200.08

1шт.

6

21603

FITTING

90º swivel elbow, 3/8" fpt x 3/8" fpt

1шт.
