Запчасти Case IH 40 (75.200.05) - ENDMARKER HYDRAULICS (75) - SOIL PREPARATION

1

87506235

REMOTE CONTROL VALVE

sequence 2 way 3 port

1шт.

2

9412

QUICK MALE COUPLING

1/2"

2шт.

3

441803A1

VALVE PRESSURE RELIE

1000 psi with reverse flow track

1шт.

4

FLX23387

FITTING

1/2" mb x 1/2" mj

2шт.

5

425883A1

HYDRAULIC CYLINDER,Double Acting, 304.8mm Stroke

2 1/2" x 12" Monarch 3000 psi

2шт.

6

425873A1

U-BOLT

us 5/16"-18 8 1/8"w 7"d -G5 2" thread

1шт.

7

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

2шт.

8

87329788

90 ELBOW,90 Degree, 9/16"-18, 37 Degree x 3/4"-16, O-Ring

2шт.

9

87331046

TEE,3/4" - 16 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC

1шт.

10

439148A1

BLOCK

aluminum

1шт.

11

9707515

BOLT,Hex, 5/16 - 18" x 1 3/4", Gr 5

2шт.

12

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

13

214389

PLUG,3/4" - 16 ORB

1шт.

14

350326A1

ISOLATOR

clamp, hose small

2шт.

15

1024284

CLAMP

HOSE FORMED 2.88 X .94

2шт.

16

425874A1

BRACKET, SUPPORTING

mount

1шт.

17

280736

NUT,5/16"-18, GC

4шт.

18

128817

HYD CONNECTOR,3/4" - 16 ORB x 9/16" - 18 JIC

4шт.

19

86624135

REDUCER,37 Degree, 3/4"-16, Fem x 9/16"-18 Male

2шт.

21

425861A1

HYDRAULIC HOSE

1/4" x 360" fl

2шт.

22

425862A1

HYDRAULIC HOSE

1/4" x 344" fl

2шт.

23

425863A1

HYDRAULIC HOSE

1/4" x 200" fl

2шт.
