Запчасти Case IH 40 (39.110.01) - DRAWPOLE (39) - FRAMES AND BALLASTING

1

87415

LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive

2шт.

2

1032745

HITCH

assembly

1шт.

3

87673848

HITCH

front

1шт.

4

425660A1

TUBE

hitch truss center RH

1шт.

5

232-14416

NUT,1"-8, GC

3шт.

6

86992215

LOCK NUT,1/2"-13, GC

1шт.

7

232-41420

LOCK NUT,1 1/4"-7, GC

2шт.

8

9706716

BOLT,Hex, 1/2" - 13 x 2", Gr 5

1шт.

9

87337

BOLT,Hex, 3/4" - 10 x 3", Gr 5

1шт.

10

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

11

426-16112

BOLT,Hex, 1" - 8 x 7", Gr 8

2шт.

12

86539260

BOLT,Hex, 1" - 8 x 3", Gr 8

1шт.

13

426-2088

BOLT,Hex, 1-1/4" - 7 x 5-1/2", Gr 8

2шт.

14

80700

WASHER,0.56" ID x 1.38" OD x 0.11" Thk

1шт.

15

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

2шт.

16

496-11131

WASHER,1 5/16" x 2 1/2" x .150", HDN

2шт.

17

1016961

JACK

2000 lb x 15"

1шт.

18

1024284

CLAMP

HOSE FORMED 2.88 X .94

2шт.

19

1026727

HOLDER

hydraulic hose

1шт.

20

GR-457A

CHAIN (AG)

assembly, safety 60,600 lb

1шт.

21

1032403

SPACER

tube 3/4"

1шт.

22

1032404

WASHER

1.281" ID 3.75" OD .375" thick

1шт.

23

1032742

PLATE

top hitch

1шт.

24

1032743

BLOCK

perfect hitch v-block

1шт.

25

1032744

HITCH

base

1шт.

26

1032751

CUSHION

perfect hitch

1шт.

27

112886C1

BUSHING

tension 1 1/2" x 1 1/4" x 1"

4шт.

28

350326A1

ISOLATOR

clamp, hose small

2шт.

29

311864A1

REFLECTOR

Retroreflective Amber 1.375" x 7.25"

2шт.

30

87653276

DECAL

Case IH (350 mm x 83 mm)

2шт.
