Запчасти Case IH 40 (39.100.02) - WING FRAME (39) - FRAMES AND BALLASTING

1

87580

LOCK PIN,7.94mm OD x 50.8mm L, Slotted

4шт.

2

87010729

JAM NUT,Jam, 1 1/2"-6, G5

2шт.

3

232-14416

NUT,1"-8, GC

4шт.

4

280375

NUT,3/4"-10, GC

18шт.

5

86509499

JAM NUT,3/8"-16, G2

4шт.

6

86639566

NUT,5/8"-11, GB

2шт.

7

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

1шт.

8

9706689

BOLT,Hex, 3/8" - 16 x 1 3/4", Gr 5

4шт.

9

280233

BOLT,Hex, 5/8" - 11 x 2 1/2", Gr 8

2шт.

10

426-1232

BOLT,Hex, 3/4" - 10 x 2", Gr 8

8шт.

11

9706701

BOLT,Hex, 3/4" - 10 x 2 1/2", Gr 5

2шт.

12

86508735

BOLT,Hex, 3/4" - 10 x 6", Gr 8

8шт.

13

86539260

BOLT,Hex, 1" - 8 x 3", Gr 8

4шт.

14

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

1шт.

15

496-11131

WASHER,1 5/16" x 2 1/2" x .150", HDN

4шт.

16

87414

LUBE NIPPLE,1/4" - 28

2шт.

17

1024284

CLAMP

HOSE FORMED 2.88 X .94

1шт.

18

87407431

HYDRAULIC CYLINDER

hyd cylinder Assembly 5" x 30" Monarch

2шт.

Includes 86990365, 1019844, 218-5106, 350401A1, 1015478, and 6-70060

1шт.

19

87403614

HEADED PIN

cylinder 1 1/4" dia 4 ul

2шт.

20

1978737C1

COTTER PIN,Int, 1/8" x 49mm

3 mm x 49 mm

4шт.

21

87674169

FRAME

truss main RH

1шт.

Shown

1шт.

21

87673485

FRAME

truss main LH

1шт.

Not Shown

1шт.

22

312986A1

CUSHION

cylinder rubber

2шт.

23

312987A1

SPACER

33 mm id x 50.8 mm od x 22 mm

4шт.

24

312991A1

PIN

winglift

2шт.

25

350326A1

ISOLATOR

clamp, hose small

1шт.

26

351861A1

BRACKET

Brace wing diagonal

1шт.

27

351865A1

BRACKET

Brace wing support

1шт.

28

439255A1

FRAME

wing truss RH

1шт.

Includes bronze bushings and two decals 350336A1

1шт.

28

439253A1

FRAME

wing truss LH

1шт.

Includes bronze bushings and two decals 350336A1

1шт.

29

351874A1

CLEVIS COUPLING

bolt on

1шт.

30

425143A1

SHIM

plate

1шт.

31

425500A2

PIVOT PIN

1 1/2" od x x 5 5/8" ul

2шт.

32

425579A1

TUBE

wing end RH

1шт.

32

425865A1

TUBE

wing end LH

1шт.

33

439173A1

WASHER

1 9/16" x 2 1/2" x 14 GA hardened

1шт.

40

425667A1

BEAM

wing front RH

1шт.

40

425668A1

BEAM

wing front LH

1шт.

41

439256A1

TUBE

wing RH

1шт.

41

439257A1

TUBE

wing LH

1шт.

42

87409045

SEAL KIT

Seal Kit For 87407431

1шт.

43

22093

BUSHING,1-1/2" ID x 1-3/4" OD x 1" Thk

1шт.

44

351879A1

SPACER

1шт.
