Запчасти Case IH CONCORD (9C-20) - PUMP DRIVE SHAFT ASSEMBLY

1

290071A1

SHAFT

Drive Wheel

1шт.

2

1018571

BEARING ASSY

/A - Pillow Block

2шт.

2a

412-512

CARRIAGE BOLT,Short Sq Nk, 5/16" - 18 x 3/4", Gr 2

CRG 5/16 x 3/4", GR5 ZP

2шт.

3

1012975

KEY

Square Parallel

1шт.

4

312293A1

SPROCKET ASSY.

15 tooth #40 Chain Hardened

1шт.

5

1021090

CLUTCH DISC

CLUTCH DISK elect. Warner 5210-25

1шт.

6

312322A1

SPROCKET ASSY.

Machined 60 tooth

1шт.

7

1013418

COLLAR

shaft

1шт.

8

495-11066

WASHER,5/8", SAE

.656 x 1.312 x .095 inch, CST, ZND

1шт.

9

80679

LOCK WASHER,1/20.507 CST ZND

1шт.

10

413-816

BOLT,Hex, 1/2" - 13 x 1", Gr 5

1шт.

11

495-11034

WASHER,5/16", SAE

(Flat, 11/32 x 11/16 x 1/16")

12шт.

12

425-106

NUT,3/8"-16, Cl 5

12шт.

13

113-368

BOLT,Hex, 3/8" - 16 x 4", Gr 5, Full Thd

THD to HD, .38" x 4.00" , GR5, ZND

4шт.

14

495-11028

WASHER,1/4", SAE

(9/32 x 5/8 x 1/16")

4шт.

15

492-11025

LOCK WASHER,1/4"

4шт.

16

426-416

BOLT,Hex, 1/4" - 20 x 1", Gr 8

4шт.

17

425-104

NUT,1/4"-20, Cl 5

4шт.

18

413-664

BOLT,Hex, 3/8" - 16 x 4", Gr 5

Hex HD, .375 x 4.00 GR5, ZND

2шт.
