Запчасти Case IH CONCORD (9C-12) - MAILBOX ASSEMBLY

1

290644A1

SHEET

firewall

1шт.

2

312151A1

INTAKE ASSY

INLET -air

1шт.

3

141207C2

DEFLECTOR

air, lower

1шт.

4

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

1шт.

5

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

1шт.

6

1264268C1

ROD

stabilizer

1шт.

7

495-21038

WASHER,5/16"

(flat, 3/8 x 7/8 x 3/32")

1шт.

8

432-616

COTTER PIN,3/32" x 1"

1шт.

9

425-105

NUT,5/16"-18, G5

1шт.

10

232-4115

LOCK NUT,5/16"-18, GC

1шт.

11

141208C1

DEFLECTOR

air, upper

1шт.

12

463-1108

SCREW,Hex Hd, #10-24 x 1/2"

1шт.

13

231-51409

SERRATED NUT,Flg, USR, #10-24

1шт.

14

57393C1

INDICATOR

BRACKET - air flow indicating

1шт.

15

57394C1

INDICATOR

BAFFLE - bypass tube

1шт.

16

231-51409

SERRATED NUT,Flg, USR, #10-24

1шт.

17

1264267C1

SUPPORT

ROD, stabilizer

1шт.

18

149310C2

CLIP

LOCK

1шт.
