Запчасти Case IH NT950 (35.100.05) - WING LIFT CYLINDERS (35) - HYDRAULIC SYSTEMS

1

84347694

HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 304.8mm Stroke

3.5 x 12, Outer Wing

1шт.

1

84347708

HYDRAULIC CYLINDER,Double Acting, 34.92mm Rod, 304.8mm Stroke

4 x 12, Main Frame

1шт.

1

84347707

HYDRAULIC CYLINDER,34.92mm Rod, 304.8mm Stroke

3.75 x 12, Inner Wing

1шт.

2

86590562

PLUG,Hex Soc, 3/4" - 16 ORB

1шт.

3

84378359

CLEVIS

4 x 12

1шт.

3

84378357

CLEVIS

3.75 X 12

1шт.

3

84378356

CLEVIS

3.5 X 12

1шт.

4

87314800

LOCK NUT

3.5 X 12

1шт.

4

87652886

NUT

4 x 12, 3.75 x 12

1шт.

5

87409469

PISTON

3.5 x 12

1шт.

5

87409472

PISTON

4 x 12

1шт.

5

87409471

PISTON

3.75 x 12

1шт.

6

84221859

PISTON ROD

3.5 x 12

1шт.

6

84221857

PISTON ROD

4 x 12, 3.75 x 12

1шт.

7

87548070

TIE-ROD

3.5 x 12, 4 x 12, 3.75 x 12

1шт.

8

87410758

CAP

3.5 x 12

1шт.

8

87409397

HEAD

4 x 12

1шт.

8

87428313

ROD

3.75 x 12

1шт.

9

408

NUT,5/8" - 18, Gr 5

1шт.

10

84212867

SET SCREW

1шт.

11

84221842

CLEVIS

3.5 x 12, 4 X 12, 3.75 x 12

1шт.

12

87409038

SEAL KIT

3.5 x 12

1шт.

12

87409033

SEAL KIT

4 x 12

1шт.

12

87409040

SEAL KIT

3.75 x 12

1шт.
