Запчасти Case IH 940 (75.200.01) - DISK SEALERS (75) - SOIL PREPARATION

1

84296819

ARM

18" Assy Side

2шт.

2

87339

BOLT,Hex, 1/2" - 13 x 3", Gr 5

2шт.

3

80700

WASHER,0.56" ID x 1.38" OD x 0.11" Thk

2шт.

4

9707516

BOLT,1/2"-13 x 1-3/4", Cl 5

4шт.

5

86992215

LOCK NUT,1/2"-13, GC

14шт.

6

84380555

DISK HARROW

HPT BLADES 18" PLAIN 3.0 MM

2шт.

6

84380560

DISK HARROW

18" Notched Blade

2шт.

7

280486

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5, Full Thd

8шт.

8

04693158

TUBE

TUBE

1шт.

9

04693165

MOUNTING PARTS

Sealer Mount Weldment

1шт.

10

84303996

ARM

Top

1шт.

11

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

1шт.

12

85700693

NUT,5/8" - 11, Gr C

3шт.

13

80299

WASHER,0.69" ID x 1.75" OD x 0.13" Thk

1шт.

14

24120701

COMPRESSION SPRING

5"

1шт.

15

17506020

CUP WASHER,16.66mm ID x 44.45mm OD x 1.52mm Thk

5/8 ID

1шт.

16

84009

BOLT

5/8-11 X 6 GR5

1шт.

17

44006204

BUSHING,16.26mm ID x 25.4mm OD x 25.4mm L

1 x 5/8 x 1

2шт.

18

17511000

BELLEVILLE WASHER

11/16

2шт.

19

87613192

WASHER,0.66" ID x 1.75" OD x 0.24" Thk

5/8

1шт.

20

04693150

SPECIAL BOLT

WELDMENT, T-BOLT

1шт.
