Запчасти Case IH 9000 (75.130.01) - TANK BREAKDOWN (75) - SOIL PREPARATION

1

05401000

Tank Assembly, Includes Everything Except 9

1шт.

2

05401300

LID

2шт.

3

05401320

LIFT LINK

Weldment

2шт.

4

05401326

LIFT LINK

4шт.

5

05401323

DRIVE BUSHING

16шт.

6

05401325

LATCH

4шт.

7

05401324

HANDLE

2шт.

8

05401340

Screen Baskets

2шт.

9

05401360

Ladder

1шт.

10

14740408

COTTER PIN

1/8" x 1" Roll

8шт.

11

14090608

SPECIAL NUT

3/8" NC Hex., Stainless

34шт.

12

14090808

1/2" NC Hex.,Stainless

4шт.

13

16306018

U-BOLT

3/8" x 1-3/4" x 2-1/4", Stainless

4шт.

14

16906028

3/8" x 1/2" NC Hex., Stainless

4шт.

15

113-2295

BOLT,Hex, 3/8" - 16 x 1", SST

NC

16шт.

16

113-2236

BOLT,Hex, 3/8" - 16 x 1-1/2", SST

NC

2шт.

17

16908069

1/2" x 1-1/2" NC Hex., Stainless

4шт.

18

17906002

3/8" Flat Washer, Stainless

20шт.

19

17906003

3/8" Lock Washer, Stainless

20шт.

20

214-1424

HOSE CLAMP,#24, 1.06" - 2", Type F Worm

Gear, Stainless

2шт.

21

25631601

1" I.D. x 56" Long

1шт.

22

18534319

Long Stripe

4шт.

23

18534318

Precision Air

2шт.

24

18534322

Short Stripe

4шт.

25

18534321

Nutri-Placr 9000

2шт.

26

18534330

Warning Sign

1шт.

27

18534323

DECAL

DMI Logo

2шт.

28

18534328

Warning Sign

1шт.

29

30001300

RUBBER SEAL

Door

8шт.
