Артикул
Название
Примечание
Количество
526990R91
PUMP
ASSY, hypro no. C-6600, 6 nylon roller, cast iron, consists of all parts marked unit A
1шт.
463269R91
PUMP ASSY, hypro no. N-7500, 8 nylon roller, ni-resist, order pump assy, 463269R92, consists of all parts marked unit B
1шт.
463269R92
PUMP ASSY, hypro no. N-7700, 7 nylon roller, ni-resist, for tractors with 540 RPM PTO, consists of all parts marked unit C
1шт.
541271R91
PUMP
ASSY, hypro no. N-7100, 7 nylon roller, ni-resist, for tractors with 1000 RPM PTO, consists of all parts marked unit D
1шт.
1
485612R1
RING, bearing retainer, 2 for unit A
1шт.
1
485620R1
RING, bearing retainer, 2 for units B, C and D
1шт.
2
485810R1
PLATE, name, unit A
1шт.
2
PLATE, name, not serviced separately, units B, C and D
1шт.
3
492087R91
BALL BEARING,0.625" ID x 1.375" OD x 0.4375"
ball, 2 for unit A
1шт.
3
ST544
BEARING, BALL,25mm ID x 52mm OD x 15mm W
2 for units B, C and D
1шт.
4
180077
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
SCREW, 5/16-18 x 3/4 znd hex-hd cap, 4 for unit A, 6 for units B, C and D
1шт.
5
485806R91
SEAL
rubber sealing member, 2 for unit A
1шт.
5
540502R91
SEAL
rubber sealing member, 2 for units B, C and D
1шт.
6
485807R91
PLATE W/SEAL ASSY, end, unit A
1шт.
6
PLATE W/SEAL ASSY, end, unit B, discontinued for service
1шт.
6
540503R91
PLATE W/SEAL ASSY, end, unit C
1шт.
6
541273R91
PLATE W/SEAL ASSY, end, unit D
1шт.
7
610411C1
O-RING,0.139" Thk x 3.484" ID, -238, Cl 5, 75 Duro
gasket end plate, unit A
1шт.
7
343700R1
O-RING,-155, 70 Duro, 3.987" ID x .103" Thk
gasket end plate, units B, C and D
1шт.
8
485811R1
ROLLER
nylon, 6 for unit A, 7 for units C and D, 8 for unit B
1шт.
9
485808R91
ROTOR ASSY, unit A
1шт.
9
485817R91
ROTOR ASSY, unit B
1шт.
9
540504R91
ROTOR ASSY, unit C
1шт.
9
541274R91
ROTOR ASSY, unit D
1шт.
10
485809R1
SHAFT, unit A
1шт.
10
SHAFT, unit B, discontinued for service
1шт.
10
540505R1
SHAFT, units C and D
1шт.
11
485805R91
BODY W/SEAL ASSY, unit A
1шт.
11
485814R91
BODY W/SEAL ASSY, unit B
1шт.
11
540501R91
BODY W/SEAL ASSY, unit C
1шт.
11
541272R91
BODY W/SEAL ASSY, unit D
1шт.
12
191950
SET SCREW,Hdls Hex Skt, 5/16" - 18 x 3/8", Cup Pt
SCREW, 5/16-18 x 3/8 znd hex-soc-hd cup point set, units A, B, C and D
1шт.
13
180075
BOLT,Hex, 5/16" - 18 x 5/8", Gr 5
SCREW, 5/16-18 x 5/8 znd hex-hd cap, 2 for unit A
1шт.
13
NLS
NO LONGER SERVICED
SCREW, 5/16-18 x 1/2 znd sq-hd cup-pt set, unit A
1шт.
13
22210R1
SET SCREW,Hex Soc, 5/16"-18 x 1/2"
SCREW, 5/16-18 x 1/2 znd hex-soc-hd cup point set, 4 for units B, C and D
1шт.
14
485813R91
ADAPTER W/SET SCREWS ASSY, for standard 1-3/8 in. PTO unit A
1шт.
14
ADAPTER W/SET SCREWS ASSY, unit B, discontinued for service
1шт.
14
540507R91
ADAPTER W/SET SCREWS ASSY, units C & D
1шт.
540511R1
KEY, spline, units C and D
1шт.
540508R91
BOLT W/NUT & LOCKWASHER, shear, units C and D
1шт.
15
485823R1
RING, bearing spacer, 2 for units B, C and D
1шт.
540506R91
KIT, repair, units B, C and D, consists of (1) o-ring 343700R1, (7) roller 485811R1, (2) seal 540502R91
1шт.
Выбрано товаров: 42
