Запчасти Case IH 610 (55.100.01) - RH CONSOLE HARNESS, 610 (55) - ELECTRICAL SYSTEMS

1

84528851

WIRE HARNESS

RH Console, All 610 Configurations, Includes Ref 2 - 33

1шт.

2

84401288

TERMINAL

Cruise Control Switch, 102L

4шт.

3

BN310610

ELEC CONNECTOR,Female, 10 Pin

Cruise Set/Resume, 103F1

1шт.

3

182136A1

TERMINAL CONNECTOR

Cruise Set/Resume, 103F1

3шт.

4

BN310610

ELEC CONNECTOR,Female, 10 Pin

Boom Lock, 105F1

1шт.

4

182136A1

TERMINAL CONNECTOR

Boom Lock, 105F1

3шт.

4

182137A1

CONNECTOR, ELEC

CONNECTOR Boom Lock, 105F1

1шт.

5

87352746

ELEC CONNECTOR

Splice 56B 12W, SP-52B1

1шт.

5

87693733

RETAINER

Splice 56B 12W, SP-52B1

1шт.

5

87352747

CAP

Splice 56B 12W, SP-52B1

1шт.

5

87693727

ELEC. TERMINAL PIN,Tin, 0.75 - 1.00mm

Splice 56B 12W, SP-52B1

5шт.

5

87693249

ELEC. TERMINAL PIN

Splice 56B 12W, SP-52B1

1шт.

6

87695723

ELEC CONNECTOR,Male , 3 Pole

Foam Volume, 113M1

1шт.

6

87695625

WIRE CONNECTOR,Locking, Green

Foam Volume, 113M1

1шт.

6

381417A1

TERMINAL,Male, Nickel, 0.50 - 1.00mm

Foam Volume, 113M1

3шт.

7

BN310610

ELEC CONNECTOR,Female, 10 Pin

Foam Marker On/Off, 114F1

1шт.

7

182136A1

TERMINAL CONNECTOR

Foam Marker On/Off, 114F1

2шт.

7

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Foam Marker On/Off, 114F1

1шт.

8

BN310610

ELEC CONNECTOR,Female, 10 Pin

Sparge Pressure, 115F1

1шт.

8

182136A1

TERMINAL CONNECTOR

Sparge Pressure, 115F1

4шт.

8

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Sparge Pressure, 115F1

2шт.

9

BN310610

ELEC CONNECTOR,Female, 10 Pin

Auxiliary Shift, 116F1

1шт.

9

182136A1

TERMINAL CONNECTOR

Auxiliary Shift, 116F1

6шт.

10

87694717

ELEC CONNECTOR

Splice Pack 3x4 Way, SP-182F1

1шт.

10

84153405

RETAINER

Splice Pack 3x4 Way, SP-182F1

1шт.

10

87695206

ELEC CONNECTOR

Splice Pack 3x4 Way, SP-182F1

1шт.

10

84526560

TERMINAL

Splice Pack 3x4 Way, SP-182F1

10шт.

10

388688A1

CONNECTOR, ELEC

CONNECTOR Splice Pack 3x4 Way, SP-182F1

1шт.

11

BN310610

ELEC CONNECTOR,Female, 10 Pin

Master Power Switch, 121F1

1шт.

11

182136A1

TERMINAL CONNECTOR

Master Power Switch, 121F1

5шт.

11

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Master Power Switch, 121F1

1шт.

12

BN310610

ELEC CONNECTOR,Female, 10 Pin

Park Brake Switch, 122F1

1шт.

12

182136A1

TERMINAL CONNECTOR

Park Brake Switch, 122F1

6шт.

12

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Park Brake Switch, 122F1

1шт.

13

87695592

CONTACT HOUSING,Female, 12 Pole

Control Handle, 101F1

1шт.

13

87695651

LOCKING TAB,Wedge Lock

Control Handle, 101F1

1шт.

13

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

Control Handle, 101F1

9шт.

14

87694112

ELEC CONNECTOR,Female, 6 Pole

Control Handle Power, 100F1

1шт.

14

87694150

LOCKING TAB,Wedge Lock

Control Handle Power, 100F1

1шт.

14

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

Control Handle Power, 100F1

5шт.

15

87692858

ELEC CONNECTOR,Male

Decel, 130M1

1шт.

15

225120C1

TERMINAL CONNECTOR,Tin, 0.8mm

Decel, 130M1

2шт.

16

87707115

CONTACT HOUSING,Female, 70 Pole

Compartment Interface, 128F1

1шт.

16

87271606

BOOT

Compartment Interface, 128F1

1шт.

16

225365C1

SOCKET

Compartment Interface, 128F1

2шт.

16

225241C1

SOCKET

Compartment Interface, 128F1

56шт.

16

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

Compartment Interface, 128F1

1шт.

17

87271908

ELEC CONNECTOR

Transmission Shifter, 905F1

1шт.

17

87271909

SEAL

Transmission Shifter, 905F1

1шт.

17

87271910

WEDGE

Transmission Shifter, 905F1

1шт.

17

87271911

PLUG

Transmission Shifter, 905F1

9шт.

17

87271913

WEDGE

Transmission Shifter, 905F1

1шт.

17

87693317

WEDGE

Transmission Shifter, 905F1

1шт.

17

87271912

WEDGE

Lock, Transmission Shifter, 905F1

1шт.

17

87693268

TERMINAL

Transmission Shifter, 905F1

7шт.

18

87352746

ELEC CONNECTOR

Splice 056A 12 Way, SP-52A1

1шт.

18

87693733

RETAINER

Splice 056A 12 Way, SP-52A1

1шт.

18

87352747

CAP

Splice 056A 12 Way, SP-52A1

1шт.

18

87693727

ELEC. TERMINAL PIN,Tin, 0.75 - 1.00mm

Splice 056A 12 Way, SP-52A1

10шт.

18

87693249

ELEC. TERMINAL PIN

Splice 056A 12 Way, SP-52A1

2шт.

19

BN16174

DIODE,600V, 3A

3A, 600V, 1CN1

1шт.

20

84177908

TERMINAL

Internal Wash, 124F1

3шт.

21

87695592

CONTACT HOUSING,Female, 12 Pole

2 Speed Axle, 126F1

1шт.

21

87695651

LOCKING TAB,Wedge Lock

2 Speed Axle, 126F1

1шт.

21

87695921

CONTACT,Female, Nickel, 0.50 - 1.00mm

2 Speed Axle, 126F1

10шт.

22

87695724

ELEC CONNECTOR,Male, 12 Pole

2 Speed Axle, 126M1

1шт.

22

87698541

LOCKING TAB,Wedge Lock, 12-Pin

2 Speed Axle, 126M1

1шт.

22

381417A1

TERMINAL,Male, Nickel, 0.50 - 1.00mm

2 Speed Axle, 126M1

11шт.

23

87694717

ELEC CONNECTOR

Splice 3x4 Way, SP-154F1

1шт.

23

84153405

RETAINER

Splice 3x4 Way, SP-154F1

1шт.

23

87695206

ELEC CONNECTOR

Splice 3x4 Way, SP-154F1

1шт.

23

388688A1

CONNECTOR, ELEC

CONNECTOR Splice 3x4 Way, SP-154F1

1шт.

23

84526560

TERMINAL

Splice 3x4 Way, SP-154F1

11шт.

24

BN310610

ELEC CONNECTOR,Female, 10 Pin

RH Tip Fold Switch, 119F1

1шт.

24

182136A1

TERMINAL CONNECTOR

RH Tip Fold Switch, 119F1

3шт.

25

BN310610

ELEC CONNECTOR,Female, 10 Pin

Boom Tip Shutoff, 60'/85' Boom, 118F1

1шт.

25

182136A1

TERMINAL CONNECTOR

Boom Tip Shutoff, 60'/85' Boom, 118F1

3шт.

25

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Boom Tip Shutoff, 60'/85' Boom, 118F1

1шт.

26

BN310610

ELEC CONNECTOR,Female, 10 Pin

LH Tip Fold Switch, 119F1

1шт.

26

182136A1

TERMINAL CONNECTOR

LH Tip Fold Switch, 119F1

2шт.

26

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

LH Tip Fold Switch, 119F1

1шт.

27

BN310610

ELEC CONNECTOR,Female, 10 Pin

Fence Row Switch, 112F1

1шт.

27

182136A1

TERMINAL CONNECTOR

Fence Row Switch, 112F1

4шт.

27

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Fence Row Switch, 112F1

2шт.

28

BN310610

ELEC CONNECTOR,Female, 10 Pin

Boom Section Switch, Section 6, 111F1

1шт.

28

182136A1

TERMINAL CONNECTOR

Boom Section Switch, Section 6, 111F1

2шт.

28

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Boom Section Switch, Section 6, 111F1

1шт.

29

BN310610

ELEC CONNECTOR,Female, 10 Pin

Boom Section Switch, Section 5, 110F1

1шт.

29

182136A1

TERMINAL CONNECTOR

Boom Section Switch, Section 5, 110F1

2шт.

29

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Boom Section Switch, Section 5, 110F1

1шт.

30

BN310610

ELEC CONNECTOR,Female, 10 Pin

Boom Section Switch, Section 4, 109F1

1шт.

30

182136A1

TERMINAL CONNECTOR

Boom Section Switch, Section 4, 109F1

2шт.

30

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Boom Section Switch, Section 4, 109F1

1шт.

31

BN310610

ELEC CONNECTOR,Female, 10 Pin

Boom Section Switch, Section 3, 108F1

1шт.

31

182136A1

TERMINAL CONNECTOR

Boom Section Switch, Section 3, 108F1

2шт.

31

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Boom Section Switch, Section 3, 108F1

1шт.

32

BN310610

ELEC CONNECTOR,Female, 10 Pin

Boom Section Switch, Section 2, 107F1

1шт.

32

182136A1

TERMINAL CONNECTOR

Boom Section Switch, Section 2, 107F1

2шт.

32

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Boom Section Switch, Section 2, 107F1

1шт.

33

BN310610

ELEC CONNECTOR,Female, 10 Pin

Boom Section Switch, Section 1, 106F1

1шт.

33

182136A1

TERMINAL CONNECTOR

Boom Section Switch, Section 1, 106F1

2шт.

33

87697753

ELEC. TERMINAL PIN,Tin, 1.00 - 2.00mm

Boom Section Switch, Section 1, 106F1

1шт.
