(35.220.02) - PTO ASSY

Запчасти Case IH 610 (35.220.02) - PTO ASSY (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 610 - (35.220.02) - PTO ASSY (35) - HYDRAULIC SYSTEMS
4
3
2
2
3
3
3
3
1
2
home
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84164940

PTO

Drive, 1.15 Engine Ratio, 15 Tooth Spline, Includes Ref 2 - 4

1шт.

2

87272068

REPAIR KIT

Mounting Gasket, Located Between Transmission and PTO, And Instructions

1шт.

3

87272631

REPAIR KIT

Mounting Bolts, Includes 8 12pt Screws And 2 Alignment Studs

1шт.

4

87265711

HYDRAULIC HOSE,28.00", SAE 100R5

PTO To Transmission

1шт.
