Артикул
Название
Примечание
Количество
1
472428R2
ANGLE, lift rod bracket
1шт.
17140R1
CARRIAGE BOLT,Short Nk, 1/2" - 13 x 1 1/4", Gr 2, Full Thd
BOLT, 1/2-13 x 1-1/4 C-Z sq-nk crg
4шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
4шт.
120384
WASHER,1/2"
LOCK, 1/2"
4шт.
2
472429R1
BAR
PAD, hopper
2шт.
3
472401R11
LID ASSEMBLY, hopper
1шт.
12235R1
PIN, 1/8 x 3/8 C-Z cot 1/8" x 5/8"
2шт.
4
472407R1
REINFORCEMENT, hopper
2шт.
5
472416R2
HOUSING
auger feed
2шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd
8шт.
120376
NUT,5/16"-18, G5
8шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
8шт.
134238R1
WASHER
11/32 x 1 x 16 ga C-Z
8шт.
6
479179R93
HOPPER
ASSY
1шт.
7
479124R1
VALVE SPRING
SPRING, hopper hold down
2шт.
8
472417R1
BEARING
auger
2шт.
9
487632R2
BAR
auger feed
1шт.
187988
COTTER PIN,3/16" x 1 1/4"
PIN, SPLIT (COTTER), 3/16" x 1 1/4"
6шт.
21650R1
LOCK PIN,5/16" x 2 1/2", Slotted
Pin, 5/16" x 2 1/2", Slotted
1шт.
10
472409R1
BOLSTER
SUPPORT, hopper lower
2шт.
18707R1
CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2
BOLT, 1/2-13 x 1 C- sq-nk crg
4шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
4шт.
120384
WASHER,1/2"
LOCK, 1/2"
4шт.
11
472410R1
RETAINER, tank
2шт.
17140R1
CARRIAGE BOLT,Short Nk, 1/2" - 13 x 1 1/4", Gr 2, Full Thd
BOLT, 1/2-13 x 1-1/4 C-Z sq-nk crg
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
178373R1
WASHER
17/32 x 1 x 16 ga C-Z
2шт.
12
472405R1
HINGE, hopper frame outer, Serial Range: 1966-1968
1шт.
17140R1
CARRIAGE BOLT,Short Nk, 1/2" - 13 x 1 1/4", Gr 2, Full Thd
BOLT, 1/2-13 x 1-1/4 C-Z sq-nk crg
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
178373R1
WASHER
17/32 x 1 x 16 ga C-Z
2шт.
13
472406R1
BRACKET, hinge, Serial Range: 1966-1968
2шт.
17452R1
BOLT,Hex, 1/2"-13 x 1 1/4", G2
1/2-13 x 1-1/4 C-Z hex-hd mach
4шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
4шт.
21628R1
PIN
1/8 x 3/4 C-Z self opening cot
2шт.
W6571
PIN, 3/8 x 1-11/16 std-hd
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
4шт.
14
626441R1
CLIP
hose lower, double disk opener
2шт.
610784R1
SPLIT PIN/SAFETY PIN,2.4mm OD x 60.345mm OAL
PIN, quick attachable cotter
2шт.
14
481967R1
CLIP
hose lower, runner opener
2шт.
19428R1
BOLT, 5/16 x 5/8 C-Z sq-nk crg
2шт.
120376
NUT,5/16"-18, G5
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
619855R1
WASHER
11/32 x 3/4 x 16 ga C-Z
2шт.
15
492853R91
SET
PACKAGE, fertilizer hose, 30 corrugations, double disk, consists of (1) clamp 860200R1, (1) clip 626441R1, (1) hose 472426R2 (NSS), (1) pin 610784R1
2шт.
15
492852R91
TUBE
PACKAGE, fertilizer hose, 43 corrugations, runner opener, consists of (1) bolt 19428R1, (1) clamp 860200R1, (1) clip 481967R1, (1) hose 482578R1 (NSS), (1) nut 120376, (1) washer 120214, (1) washer 619855R1
1шт.
16
860200R1
HOSE CLAMP,#36, 2 1/4", Spring
CLAMP, hose upper
2шт.
17
472404R1
HINGE, hopper frame inner, Serial Range: 1966-1968
1шт.
17140R1
CARRIAGE BOLT,Short Nk, 1/2" - 13 x 1 1/4", Gr 2, Full Thd
BOLT, 1/2-13 x 1-1/4 C-Z sq-nk crg
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
18
472414R1
COUPLING
auger long
1шт.
18
472415R1
SPACER
COUPLING, auger short
1шт.
For narrow row dry fertilizer attachment.
1шт.
89375H
CLEVIS PIN
PIN, 1/4 x 1-19/32 rod end
1шт.
112726
COTTER PIN,1/16" x 1/2"
PIN, SPLIT (COTTER), 1/16" x 1/2"
1шт.
520177R1
PIN
quick attachable cotter
1шт.
19
480968R1
SPACER
auger housing
1шт.
For narrow row dry fertilizer attachment.
1шт.
18674R1
BOLT,Short NK, 5/16"-18 x 1 1/2", G2
5/16-18 x 1-1/2 C-Z sq-nk crg
2шт.
120376
NUT,5/16"-18, G5
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
134238R1
WASHER
11/32 x 1 x 16 ga C-Z
2шт.
20
472400R2
DIVIDER, fertilizer hopper center, as divider into hopper assy, 479179R93
1шт.
21
(Not used in this application)
1шт.
22
489789R2
BRACKET
ASSY, fertilizer outer, 1969 and since
1шт.
17140R1
CARRIAGE BOLT,Short Nk, 1/2" - 13 x 1 1/4", Gr 2, Full Thd
BOLT, 1/2-13 x 1-1/4 C-Z sq-nk crg
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
178373R1
WASHER
17/32 x 1 x 16 ga C-Z
2шт.
23
489791R2
BRACKET ASSY, fertilizer inner, 1969 and since
1шт.
17140R1
CARRIAGE BOLT,Short Nk, 1/2" - 13 x 1 1/4", Gr 2, Full Thd
BOLT, 1/2-13 x 1-1/4 C-Z sq-nk crg
6шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
6шт.
120384
WASHER,1/2"
LOCK, 1/2"
6шт.
