Артикул
Название
Примечание
Количество
1
57794C3
SHEET, side LH, built 1972 through 1976
1шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd
1шт.
18475R1
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 2
5/16 x 1-1/4 znd hex-hd mach
1шт.
21496R1
WASHER
11/32 x 3/4 x 11 ga C-Z
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
120376
NUT,5/16"-18, G5
2шт.
2
57795C3
SHEET, side RH, built 1972 through 1976
1шт.
18494R1
BOLT,Hex, 3/8" - 16 x 1", Gr 2
3/8-16 x 1 znd hex-hd mach
1шт.
607895R1
WASHER
17/32 x 1 x 11 ga C-Z
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
120377
NUT,3/8" - 16, Gr 5
1шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd
1шт.
18475R1
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 2
5/16 x 1-1/4 znd hex-hd mach
1шт.
21496R1
WASHER
11/32 x 3/4 x 11 ga C-Z
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
120376
NUT,5/16"-18, G5
2шт.
3
56790C1
SHAFT
sprocket, 9.2 in. long, built 1972 through 1976
1шт.
137185
COTTER PIN,1/8" x 1"
PIN, SPLIT (COTTER), 1/8" x 1"
2шт.
4
56701C1
CLIP, hose, 295 planter
1шт.
18764R1
HARDWARE,Hex, 5/16"-18 x 3/4", G2
BOLT, 5/16 x 3/4 znd hex-hd mach
2шт.
20180R1
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2", Gr 2
BOLT, 1/2-13 x 2 znd sq-nk crg
2шт.
120376
NUT,5/16"-18, G5
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
4шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
5
56687C1
BOLT, 7/16-14 x 3 znd hex-hd mach
1шт.
NLS
NO LONGER SERVICED
NUT, 7/16-14 znd hex
1шт.
272122
BUSHING
7/16-14 znd hex jam
1шт.
120383
LOCK WASHER,Helical Spring, 7/16"
WASHER, LOCK, 7/16"
1шт.
21029R1
WASHER
15/32 x 1 x 11 ga C-Z
1шт.
607895R1
WASHER
15/32 x 1 x 16 ga znd
1шт.
6
56686C1
SPACER
drive shaft
1шт.
364437R1
PIN,3/16" x 7/8", Coiled
1шт.
7
539766R2
SPROCKET ASSY.
SPROCKET W/HUB, 42 teeth, built 1972 through 1976
1шт.
22915R1
PIN, 1/8 x 1-3/4 C-Z cot
1шт.
8
57800C2
STRAP
ASSY, idler
1шт.
18494R1
BOLT,Hex, 3/8" - 16 x 1", Gr 2
3/8-16 x 1 znd hex-hd mach
1шт.
120377
NUT,3/8" - 16, Gr 5
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
477589R1
WASHER
13/32 x 1-1/2 x 11 ga znd
1шт.
9
57796C1
ROLLER
chain tightener
1шт.
137185
COTTER PIN,1/8" x 1"
PIN, SPLIT (COTTER), 1/8" x 1"
1шт.
23559R1
WASHER
13/32 x 1-7/8 x 16 ga C-Z
1шт.
21041R1
WASHER
.531 x 2 x 16 ga znd
1шт.
10
548140R2
BUSHING
chain tightener
1шт.
11
543743R2
SPRING
chain tightener
1шт.
18481R1
COTTER PIN,3/16" x 1"
PIN, SPLIT (COTTER), 3/16" x 1"
1шт.
12
56679C2
ROD ASSY, tie
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
4шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
4шт.
13
56791C1
HANDLE
hopper support
1шт.
22957R1
PIN, 1/4 x 2-1/2 znd slt spring
1шт.
18481R1
COTTER PIN,3/16" x 1"
PIN, SPLIT (COTTER), 3/16" x 1"
1шт.
14
486830R1
COTTER PIN
PIN, quick attachable cot
1шт.
15
548513R2
SHIELD, chain
1шт.
18770R1
BOLT,Hex, 5/16"-18 x 2 3/4", G2
5/16 x 2-3/4 znd hex-hd mach
3шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
3шт.
120376
NUT,5/16"-18, G5
6шт.
16
56690C1
ROD
tie, 295 planter
1шт.
16
125556C1
ROD, tie, 296 and 386 planters
1шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
120376
NUT,5/16"-18, G5
2шт.
17
CHAIN, hopper drive, use 85 links from 10 ft roll marked, 489766R91, one connecting link, 489467R1 and one offset link, 489468R91, built 1972 through 1976
1шт.
18
56689C1
SPACER, shield long, 9.67 in. long, 295 planter
1шт.
18
125555C1
SPACER, shield long, 11.04 in. long, 296 and 386 planters
1шт.
19
56700C1
BRACKET, hose support, 295 planter
1шт.
18708R1
BOLT,Short NK, 1/2"-13 x 1 3/4", G2
1/2 x 1-3/4 znd sq-nk crg
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
20
M43715
SPACER, shield, 1/4 x 1-7/8 std pipe
3шт.
21
125530C1
BAR
tightener spring, clip
1шт.
22
274085R91
HOSE CLAMP,#10, 0.56/1.06 Type F Worm
CLAMP, hose
1шт.
23
HOSE, front insecticide, 20 in. long, make from 100 ft roll, 59187C1
1шт.
24
56685C1
SPROCKET ASSY.
SPROCKET AND AXLE ASSY, 10 tooth, 295 planter, built 1972 through 1976
1шт.
24
56688C1
SPROCKET AND AXLE ASSY, 10 tooth, 296 planter
1шт.
24
61922C1
SPROCKET AND AXLE ASSY, 10 tooth, 386 planter, built 1972 through 1976
1шт.
464623R1
WASHER
.656 x 1.50 x .105
1шт.
25
125634C1
SHEET, side LH, built 1977 and since
1шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
CARRIAGE, , 295 Planter Short NK, 5/16"-18 x 1", G2, Full Thd
1шт.
16888R1
HARDWARE,Short NK, 5/16"-18 x 1 1/4", G2
BOLT, 5/16-18 x 1-1/4 znd sq-nk crg, 386 planter
1шт.
18475R1
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 2
5/16 x 1-1/4 znd hex-hd mach
1шт.
21496R1
WASHER
11/32 x 3/4 x 11 ga C-Z
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
120376
NUT,5/16"-18, G5
2шт.
26
125633C1
SHEET, side RH, built 1977 and since
1шт.
18494R1
BOLT,Hex, 3/8" - 16 x 1", Gr 2
3/8-16 x 1 znd hex-hd mach
1шт.
607895R1
WASHER
17/32 x 1 x 11 ga C-Z
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
120377
NUT,3/8" - 16, Gr 5
1шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
CARRIAGE, , 295 Planter Short NK, 5/16"-18 x 1", G2, Full Thd
1шт.
16888R1
HARDWARE,Short NK, 5/16"-18 x 1 1/4", G2
BOLT, 5/16-18 x 1-1/4 znd sq-nk crg, 386 planter
1шт.
18475R1
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 2
5/16 x 1-1/4 znd hex-hd mach
1шт.
21496R1
WASHER
11/32 x 3/4 x 11 ga C-Z
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
120376
NUT,5/16"-18, G5
2шт.
27
128605C1
BAR
SHAFT, sprocket, 6.9 in. long, built 1977 and since
1шт.
137185
COTTER PIN,1/8" x 1"
PIN, SPLIT (COTTER), 1/8" x 1"
2шт.
28
125729C1
YOKE
hopper drive, built 1977 and since
1шт.
NLS
NO LONGER SERVICED
.531 x 1.062 x .74 znd
1шт.
120384
WASHER,1/2"
LOCK, 1/2"
1шт.
120236
NUT, 1/2-13 znd hex jam
1шт.
29
125640C1
BUSHING
sprocket, built 1977 and since
1шт.
30
125641C1
HOUSING
sprocket support, bearing, built 1977 and since
1шт.
18764R1
HARDWARE,Hex, 5/16"-18 x 3/4", G2
BOLT, 5/16 x 3/4 znd hex-hd mach
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
120376
NUT,5/16"-18, G5
2шт.
31
125638C1
SPROCKET ASSY.
SPROCKET, 42 teeth, built 1977 and since
1шт.
32
128640C1
SPROCKET ASSY.
SPROCKET AND AXLE ASSY, 10 tooth, 295 planter, built 1977 and since
1шт.
32
128641C1
SPROCKET AND AXLE ASSY, 10 tooth, 386 planter, built 1977 and since
1шт.
464623R1
WASHER
.656 x 1.50 x .105
1шт.
33
CHAIN, hopper drive, use 85 links from 10 ft roll marked, 475879R91, one connecting link, 1306D and one offset link, 1308D, built 1977 and since
1шт.
34
56702C1
SUPPORT, hose, 296 and 386 planters
1шт.
18767R1
BOLT,Hex, 5/16"-18 x 2", G2
5/16-18 x 2 znd hex-hd mach
1шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
1шт.
120376
NUT,5/16"-18, G5
1шт.
35
484192R1
SPACER, 11/16 x 13/16 x 1-5/16, 296 and 386 planters
2шт.
Выбрано товаров: 116
