Запчасти Case IH 407 (Q-6) - HOPPER SUPPORT AND DRIVE

1

519387R91

FRAME, left hopper

1шт.

1

519388R91

FRAME, right hopper

1шт.

30577B

BOLT (SPREADER),Hex, 3/4" - 10 x 1 1/2"

SCREW, 3/4 x 1-1/2 in. conical-hd cap

4шт.

2

515207R2

SUPPORT, hopper bracket

1шт.

BOLT, 1/2 x 1-3/4 in. mach

1шт.

BOLT, 1/2 x 2 in. mach

1шт.

BOLT, 1/2 x 3-3/4 in. mach

1шт.

WASHER, 1/2 in. lock

1шт.

3

519390R1

EXTENSION, hopper frame, Serial Range: 1955-1956

1шт.

3

523704R1

EXTENSION, hopper frame, 1957 and since

1шт.

4

513999R3

BRACKET

hopper

1шт.

BOLT, 1/2 x 1-1/2 in. crg

2шт.

WASHER, 1/2 in. lock

2шт.

WASHER, 17/32 x 1-1/4 in. x 16 ga

2шт.

5

519381R1

SHAFT, inner feed

1шт.

6

519382R1

SHAFT, outer feed

1шт.

PIN, 1/4 x 1-1/4 in. self-opening cotter

12шт.

WASHER, 25/32 x 1-1/4 in. x 16 ga

12шт.

7

PO1818

BUSHING

BEARING, feed shaft

1шт.

8

109350

FITTING, 1/8 in. 67-1/2 degree elbow lubrication, in feed shaft bearings

1шт.

9

513998R1

PINION

hopper drive, 13T

1шт.

PIN, 1/8 x 5/8 in. self-opening cotter

1шт.

Q3514

HEADED PIN,1/4" x 1 9/16"

PIN, 1/4 x 1-9/16 in. dld-std-hd

1шт.

10

519393R1

COUPLING, feed shaft, Serial Range: 1955-1956

1шт.

10

523707R1

COUPLING, feed shaft, 1957 and since

1шт.

PIN, 1/8 x 5/8 in. self-opening cotter

2шт.

PIN, 1/4 x 1-3/8 in. headed

2шт.

11

CHAIN, drive, use no. 32 steel links from 10 ft. roll no. CS-32

1шт.

12

518106R1

SPROCKET, drive tractor axle, 21T

1шт.

BOLT, 3/8 x 1-3/4 in. mach

6шт.

WASHER, 3/8 in. lock

6шт.

13

518101R2

HUB, drive sprocket split

1шт.

BOLT, 1/2 x 3-1/4 in. mach

2шт.

WASHER, 1/2 in. lock

2шт.

14

518521R1

SHIM, drive sprocket, for 300 tractors when not equipped with heavy duty rear axle

1шт.

15

518107R1

SPROCKET, left drive, 13T

1шт.

15

518108R1

SPROCKET, right driven, 13T

1шт.

16

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, , In 13 tooth drive sprocket 1/8"-27 x .66 lg

1шт.

17

515063R1

LINK, clutch throw-out rod

1шт.

PIN, 1/8 x 1 in. self-opening cotter

1шт.

18

PO2097A

CLUTCH

left drive

1шт.

18

PO1933A

CLUTCH

right drive

1шт.

19

PO125

SPRING

clutch throw-out. 1-1/32 in. OD, 2-1/4 in. long, 8 coils

1шт.

20

519392R1

ROD, throw-out

1шт.

PIN, 1/8 x 5/8 in. self-opening cotter

1шт.

512353R1

PIN, quick-attachable cotter

1шт.

21

514547R11

COLLAR CLAMP

COLLAR W/SET SCREW

1шт.

SCREW, 5/16 x 1/2 in. cup-pt sq-hd set

1шт.

22

11100D

SPRING

throw-out rod, 5/8 in. OD x 2-3/4 in. long, 15 coils

1шт.

23

PO2437

PIVOT

SWIVEL, throw-out rod

1шт.

PIN, 1/8 x 5/8 in. self-opening cotter

1шт.

24

519383R1

BELLCRANK, throw-out rod

1шт.

BOLT, 3/8 x 1 in. mach

1шт.

WASHER, 13/32 x 1 in. x 16 ga

2шт.

25

515065R2

ARM, chain idler sprocket

1шт.

Pin, 1/8 x 1 in. self-opening cotter

3шт.

PIN, 3/16 x 1-1/4 in. self-opening cotter

1шт.

26

515073R91

BRACKET, left throw-out

1шт.

26

515074R91

BRACKET, right throw-out

1шт.

BOLT, 1/2 x 3-1/2 in. mach

4шт.

PIN, 3/16 x 1 in. cotter

4шт.

27

PO7

SPRING

chain tightener, 3/4 in. OD, 4-1/8 in. long, 42-1/4 coils

1шт.

28

513987R11

SPROCKET W/FITTING, ldler, 7T

1шт.

29

PO23196

KEY

feed shaft

1шт.

30

125617

LUBE NIPPLE,3/16" x .61 lg, Drive

FITTING, 3/16 in. drive type straight lubrication, in chain idler and frive sprockets

1шт.

31

519391R1

CLIP, throw-out rod

1шт.

BOLT, 1/2 x 2 in. crg

1шт.

32

523957R1

ROD, throw-out

1шт.

PIN, 1/8 x 5/8 in. self-opening cotter

1шт.

512353R1

PIN, quick-attachable cotter

1шт.

33

512357R11

U-BOLT W/NUTS, throw-out rod bracket

1шт.

NUT, 3/8 in.

2шт.

WASHER, 3/8 in. lock

1шт.

34

523580R2

BRACKET, throw-out rod

1шт.
