Запчасти Case IH TITAN 4540 (55.100.AG[01]) - WIRE HARNESS, MAIN FRAME LAYOUT (55) - ELECTRICAL SYSTEMS

1

84428831

HARNESS

Tail light

1шт.

See 55.511.AJ 01 For Service

1шт.

2

47545125

WIRE HARNESS

Main Frame, 4 Wheel

1шт.

See 55.100.AI 01 For Service

1шт.

3

47826211

WIRE HARNESS

Engine Harness

1шт.

See 55.015.AB 01 For Service

1шт.

4

84340333

BASE PLATE

Tie

9шт.

5

84360210

BASE

Tie

5шт.

6

47624541

GUARD

Wiring Harness

1шт.

7

895-18010

WASHER,10.5mm ID x 18mm OD x 1.6mm Thk

1шт.

8

87344209

NUT,M10 x 1.5, Cl 10, DOR

1шт.

9

BN570007

STRAP

Black, 14-1/2" Long

46шт.

10

84407295

BASE

M8, Stud

12шт.

11

87529314

WASHER,6.6mm ID x 12.5mm OD x 2mm Thk

6.6 x 12.5 x 2 mm, HDN, DOR

4шт.

12

86980513

NUT,Prev Torque, Hex, M6, 1mm Pitch, Cl 8, DOR

8шт.

13

87529316

WASHER,9mm ID x 21mm OD x 2.5mm Thk

14шт.

14

86980514

LOCK NUT,Hex, M8, Cl 8, DOR

10шт.

15

84475841

MOUNT

Connector

2шт.

16

84318554

DECAL

Bulkhead Layout

1шт.

17

84360209

BASE

Tie

2шт.

18

86980381

BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8

2шт.

19

86980385

BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8

1шт.

20

84603751

SPACER

Braided Line

1шт.

21

47464132

MOUNT

Electric Bulkhead

1шт.

22

84526828

STRAP

Fir Tree, Cable Tie

1шт.

23

84292754

CLIP,Cable Tie W/ Fir Tree, 5mm OD x 203mm OAL

3шт.

24

47395250

CABLE TIE,200mm L

2шт.

25

47391607

FASTENER

Edge Clip

1шт.

26

86980361

BOLT,Hex, M6 x 1 x 25mm, Cl 8.8, Full Thd

1шт.

27

10399180

RING,12mm ID x 24mm OD x 11mm Thk

Grommet

1шт.

28

87529312

WASHER,11mm ID x 24mm OD x 3mm Thk

3шт.

29

86980401

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd

2шт.

30

86980515

NUT,Hex, M10 x 1.5, Cl 8.8, DOR

4шт.

31

87529315

WASHER,9mm ID x 17mm OD x 2mm Thk

1шт.

32

BN304292

COVER

Nylon Hose Cover, Bulk

1шт.

33

86980380

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd

1шт.

34

87529301

WASHER,5.6mm ID x 10mm OD x 1mm Thk

4шт.

35

87343600

SCREW,Phil Pan Hd, M5 x 16mm, Cl 4.8, Full Thd

4шт.

36

87529302

WASHER,6.6mm ID x 18mm OD x 1.6mm Thk

1шт.
