Запчасти Case IH TITAN 4520 (02-032) - STARTER GROUP (01) - ENGINE

1

193432A2

MOTOR,12V, 4.8kW

starter, 12V

1шт.

1

193432A2GV

STARTER MOTOR,12V, 4.8kW

Value, 12 Volt

1шт.

2

412123

LOCK WASHER,13.1mm ID x 21.1mm OD x 2.55mm Thk

1шт.

3

9706685

NUT,M12 x 1.75, Cl 8

1шт.

4

J920447

FLANGE BOLT,M12 x 40mm, Cl 10.9

FLANGED M12 X 40 10.9

3шт.

5

258820A1

SCREW

M5 x 8

1шт.

6

86509828

LOCK WASHER,M5

1шт.

7

87661430

SPACER

Starter, CDC

1шт.
