Запчасти Case IH TITAN 4520 (02-029) - GRID HEATER, GROUP (01) - ENGINE

1

87455571

SOLENOID

200A GRID HEATER

1шт.

2

87341554

COVER

Grid Heater Relay

1шт.

3

BN69860

CIRCUIT BREAKER

150A

1шт.

4

87529314

WASHER,6.6mm ID x 12.5mm OD x 2mm Thk

6.6 x 12.5 x 2 mm, HDN, DOR

4шт.

5

120100

BOLT,M6 x 20mm, Cl 8.8

2шт.

6

353308

NUT,M6 x 1.0, Cl 8

4шт.

7

87533675

CABLE

BATTERY TO GRID HE

1шт.

8

87533679

CABLE

GRID FUSE TO GRID

1шт.

9

87533682

CABLE

GRID RELAY TO HEAT

1шт.
