Запчасти Case IH TITAN 4520 (02-001) - ENGINE GROUP, TITAN 4020 (01) - ENGINE

1

87495312

ENGINE

9L 305 HP T3, Start Serial: Y8TO24142

1шт.

1

87461050

9L 305 HP T3, Serial Range: -Y8T024141

1шт.

2

BN314866

300 CDC

1шт.

See Fig. 02-032

1шт.

3

87272775

1шт.

See Fig. 02-006

1шт.

5

BN317988

FITTING

12MP-12FP

1шт.

4

NS

NOT SERVICED

Package, Engine Alternator, Start Year: 01-AUG-09

1шт.

See Fig. 02-031

1шт.

4

BN324041

ENGINE, Years: -01-AUG-09

1шт.

See Fig. 02-030

1шт.

6

217-145

ELBOW,45 Degree Elbow, 3/4" Hose Barb x 3/4" Male NPTF

1шт.

7

PL

PROCURE LOCALLY

1 QT DIESEL EN

24шт.

11

BN51937

ELBOW

FT, 90D, 3/4 NPTF, STL STRT

1шт.

12

217-381

FITTING,5/8" Hose Barb x 3/4" Male NPTF

2шт.

13

86010402

CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type

1шт.

14

86980379

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

1шт.

15

87529315

WASHER,9mm ID x 17mm OD x 2mm Thk

9 x 17 x 2 mm, HDN, DOR

2шт.

16

9991588

NUT,M8 x 1.25, Cl 8

1шт.

17

87271501

3.5 TURBO ELBOW

1шт.

See Fig. 02-015

1шт.

18

BN53591

FITTING

10MJ-8MB

1шт.

19

87535395

FITTING

10GS-10FJX90S, 90º Elbow

1шт.

20

87537782

HOSE,19.05 mm ID x 250.00 mm

Crankcase Breather

1шт.

21

507586

HOSE CLAMP,20.6mm - 44.4mm, Worm Gear

1шт.
