Запчасти Case IH TITAN 4040 (10.500.AD[01]) - DEF/ADBLUE™ LINES (10) - ENGINE

Схема запчастей Case IH TITAN 4040 - (10.500.AD[01]) - DEF/ADBLUE™ LINES (10) - ENGINE
12
9
27
2
9
18
30
14
20
26
15
13
12
12
10.500.ad 02
17
3
12
11
23
1
12
11
24
12
14
29
20
13
25
9
9
23
11
9
11
9
9
7
9
17
28
14
17
11
22
31
19
11
6
5
4
21
13
9
8
11
17
16
10
20

Артикул

Название

Примечание

Количество

1

47537810

INJECTOR, EMISSIONS,12 KG/HR

Denox 2.2

1шт.

1

47537810R

REMAN-INJEC EMISSION

Denox

1шт.

1

47537810C

CORE-INJEC EMISSION

Return Number

1шт.

2

84381516

TEE

DEF Heater

2шт.

3

47450068

MOUNT

Module

1шт.

4

47582287

HOSE

Doser

1шт.

5

47667915

HOSE

SM To Tank

1шт.

6

84483089

HEATER

Valve

1шт.

7

47466860

HOSE

DEF Coolant Supply

1шт.

8

47471502

HOSE

DEF Bundle

1шт.

9

87529312

WASHER,11mm ID x 24mm OD x 3mm Thk

16шт.

10

47773688

SUPPORT

DEF Bundle

1шт.

11

86980401

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd

11шт.

12

86980515

NUT,Hex, M10 x 1.5, Cl 8.8, DOR

6шт.

13

87529316

WASHER,9mm ID x 21mm OD x 2.5mm Thk

12шт.

14

86980514

LOCK NUT,Hex, M8, Cl 8, DOR

7шт.

15

86980387

BOLT,Hex, M8 x 70mm, Cl 8.8

M8 x 70mm, DOR

3шт.

16

1348264C1

HOSE CLAMP

3/8" ID

2шт.

17

515-23412

CLAMP,1 5/8", Insul, 3/8" Bolt

10шт.

18

86980400

BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd

3шт.

19

1954736C1

HOSE CLAMP,#24

4шт.

20

BN570007

STRAP

Black, 14-1/2" Long

4шт.

21

47565939

ECU

Denox 2.2 Supply

1шт.

See 10.500.AD 02 For Service

1шт.

21

47565939R

REMAN ELECT CONTROL

Denox 2.2 Supply

1шт.

21

47565939C

CORE-ELECTRONIC CONT

Return Number

1шт.

22

86980389

BOLT,Hex, M8 x 1.25 x 90mm, Cl 8.8

3шт.

23

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

5шт.

24

14432221

HEX SOC SCREW,M6 x 1.0 x 28mm, Cl 8.8

3шт.

25

515-23333

CLAMP,1 5/16", Insul, 3/8" Bolt

1шт.

26

84292754

CLIP,Cable Tie W/ Fir Tree, 5mm OD x 203mm OAL

2шт.

27

47595906

HOSE

DEF Coolant

1шт.

28

86980513

NUT,Prev Torque, Hex, M6, 1mm Pitch, Cl 8, DOR

2шт.

29

515-22127

CLAMP,1/2", Insul, 5/16" Bolt

1шт.

30

87529315

WASHER,9mm ID x 17mm OD x 2mm Thk

2шт.

31

86980379

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

1шт.

Выбрано товаров: 36
