Запчасти Case IH TITAN 3530 (55.100.07) - DENOX ENGINE HARNESS (55) - ELECTRICAL SYSTEMS
№
Артикул
Название
Примечание
Количество
1
84518433
WIRE HARNESS
Engine, Denox, Includes Ref 2 - 17
1шт.
2
87312843
FUSE BOX
Denox External Fuse/Relay Box, X-810F1
1шт.
2
87655334
RELAY,12V, 35A, Micro
Denox External Fuse/Relay Box, X-810F1
4шт.
2
121412A1
FUSE,10A, Mini, Red
Denox External Fuse/Relay Box, X-810F1
1шт.
2
121414A1
FUSE,20A, Mini, Yellow
Denox External Fuse/Relay Box, X-810F1
3шт.
2
121416A1
FUSE,30A, Mini, Green
Denox External Fuse/Relay Box, X-810F1
1шт.
2
87686742
PLUG
Denox External Fuse/Relay Box, X-810F1
11шт.
2
292550A1
SEAL
Denox External Fuse/Relay Box, X-810F1
7шт.
2
87704966
TERMINAL
Denox External Fuse/Relay Box, X-810F1
10шт.
2
87680701
SEAL
Denox External Fuse/Relay Box, X-810F1
10шт.
2
84392736
TERMINAL CONNECTOR
Denox External Fuse/Relay Box, X-810F1
22шт.
2
87698530
SEAL
Denox External Fuse/Relay Box, X-810F1
22шт.
3
84062580
CONNECTOR, ELEC
CONNECTOR DEF Tank Sensor, X-803F1
1шт.
3
82012085
TERMINAL CONNECTOR,Female, Tin, 0.75 - 1.5mm
DEF Tank Sensor, X-803F1
3шт.
4
225065C1
ELEC CONNECTOR,3.00 - 5.00mm
CONNECTOR Chassis Ground, G1-DX
1шт.
5
87695723
ELEC CONNECTOR,Male , 3 Pole
Product Harness Interface, X-505M1
1шт.
5
381417A1
TERMINAL,Male, Nickel, 0.50 - 1.00mm
Product Harness Interface, X-505M1
1шт.
5
86500035
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
Product Harness Interface, X-505M1
2шт.
6
87448363
WIRE CONNECTOR,Female
Power Interface, X-506F1
1шт.
6
87707796
ELEC CONNECTOR
Power Interface, X-506F1
1шт.
6
87695923
TERMINAL
Power Interface, X-506F1
4шт.
7
87705971
CONTACT
Urea Dosing Injecter, X-804F1
2шт.
7
87705976
SEAL
Urea Dosing Injecter, X-804F1
2шт.
8
87705971
CONTACT
Upstream Exhaust Temp Sensor, X-827F1
2шт.
8
87705976
SEAL
Upstream Exhaust Temp Sensor, X-827F1
2шт.
9
84260359
TERMINAL CONNECTOR,Tin, 10.00 - 16.00mm
Power Distribution Box, PD4
1шт.
10
87695580
ELEC CONNECTOR,Female, 3 Pole
NOX Terminator, X-826F1
1шт.
10
84058194
PLUG
NOX Terminator, X-826F1
1шт.
10
84068583
PLUG,12 - 16 Ga, White
NOX Terminator, X-826F1
1шт.
10
225365C1
SOCKET
NOX Terminator, X-826F1
2шт.
11
84058092
CONTACT HOUSING,120 Ohm Resistor
NOX Terminator, X-826M1, 120 Ohm Terminating Resistor
1шт.
11
87695625
WIRE CONNECTOR,Locking, Green
NOX Terminator, X-826M1, 120 Ohm Terminating Resistor
1шт.
12
84178654
ELEC CONNECTOR
Engine Harness Interface, X-802M1
1шт.
12
84068583
PLUG,12 - 16 Ga, White
Engine Harness Interface, X-802M1
6шт.
12
87695915
ELEC. TERMINAL PIN,Male, Nickel, 1 - 2 mm
Engine Harness Interface, X-802M1
2шт.
12
225366C1
ELEC. TERMINAL PIN,Male, Gold, 0.75 - 2.00mm
Engine Harness Interface, X-802M1
4шт.
13
84190317
WIRE CONNECTOR,Female, 5 Cavities
Dosing Module, X-825F1
1шт.
13
87709655
BLANK-OFF PLUG
Dosing Module, X-825F1
1шт.
13
84190318
TERMINAL CONNECTOR
Dosing Module, X-825F1
4шт.
14
87705971
CONTACT
Downstream Exhaust Temp Sensor, X-828F1
2шт.
14
87705976
SEAL
Downstream Exhaust Temp Sensor, X-828F1
2шт.
15
84192117
ELEC CONNECTOR
Urea Heating Valve, X-829F1
1шт.
15
84190318
TERMINAL CONNECTOR
Urea Heating Valve, X-829F1
2шт.
16
84262038
WIRE CONNECTOR
Converter +24V, X-824F1
1шт.
16
84257517
TERMINAL CONNECTOR,3.00 - 5.00mm
Converter +24V, X-824F1
4шт.
17
87713291
WIRE CONNECTOR
DCU, X-823F1
1шт.
17
87713299
ADAPTER
DCU, X-823F1
1шт.
17
87713301
CAP
DCU, X-823F1
1шт.
17
87713302
SCREW,Phillips Drive, Round HD, M3 x 12mm
DCU, X-823F1
1шт.
17
82035902
PLUG
DCU, X-823F1
12шт.
17
12309290
CABLE TERMINAL
DCU, X-823F1
16шт.
17
87691478
SEAL
DCU, X-823F1
16шт.
17
87679949
TERMINAL CONNECTOR
DCU, X-823F1
4шт.
Выбрано товаров: 59
