Запчасти Case IH TITAN 3530 (55.100.04) - CAB ROOF HARNESS (55) - ELECTRICAL SYSTEMS

1

84316433

HARNESS

Cab Roof

1шт.

2

245483C1

ELEC CONNECTOR,Male, 2 Pin

Left Front Work Light, DC935F

1шт.

3

245482C1

ELEC CONNECTOR,2 Pin

Left Front Work Light, C935M

1шт.

4

371614A1

ELEC CONNECTOR,Female, 2 Pin

Patio Lamp, C930

1шт.

5

245483C1

ELEC CONNECTOR,Male, 2 Pin

Left Rear Work Light, DC937F

1шт.

6

245482C1

ELEC CONNECTOR,2 Pin

Left Rear Work Light, C937M

1шт.

7

371614A1

ELEC CONNECTOR,Female, 2 Pin

Rear Left Hazard Lamp, C918

1шт.

8

245482C1

ELEC CONNECTOR,2 Pin

Rear Left Outboard Worklight, C913M

1шт.

9

245482C1

ELEC CONNECTOR,2 Pin

Rear Left Inboard Worklight, C910M

1шт.

10

245482C1

ELEC CONNECTOR,2 Pin

Rear Right Inboard Worklight, C911M

1шт.

11

245482C1

ELEC CONNECTOR,2 Pin

Rear Right Outboard Worklight, C912M

1шт.

12

371614A1

ELEC CONNECTOR,Female, 2 Pin

Rear Right Hazard Lamp, C916

1шт.

13

245482C1

ELEC CONNECTOR,2 Pin

Right Rear Work Light, C938M

1шт.

14

245483C1

ELEC CONNECTOR,Male, 2 Pin

Right Rear Work Light, DC938F

1шт.

15

84177904

ELEC CONNECTOR,Female, 5 Cavities

Rear Wiper Motor, C914

1шт.

16

84178654

ELEC CONNECTOR

Cab Roof Bulkhead, C013M

1шт.

17

84179099

ELEC CONNECTOR

Cab Roof Bulkhead, C010M

1шт.

18

245482C1

ELEC CONNECTOR,2 Pin

Right Front Work Light, C936M

1шт.

19

245483C1

ELEC CONNECTOR,Male, 2 Pin

Right Front Work Light, DC936F

1шт.

20

276426A1

ELEC CONNECTOR,Male, 3 Pin

Right Electric Mirror, C929F

1шт.

21

276424A1

ELEC CONNECTOR,Female, 3 Pin

Right Electric Mirror, DC929M

1шт.

22

371614A1

ELEC CONNECTOR,Female, 2 Pin

Front Right Hazard Lamp, C925

1шт.

23

245715C1

ELEC CONNECTOR,4 Pin

Front Wiper Motor, C921M

1шт.

24

245480C1

ELEC CONNECTOR,1 Pin

Front Wiper Motor, C922M

1шт.

25

225316C1

ELEC CONNECTOR,Female, 2 Pin

Strobe/Beacon Lamp, C920M

1шт.

26

225315C1

ELEC CONNECTOR,Male, 2 Pin

Strobe/Beacon Lamp, DC920F

1шт.

27

371614A1

ELEC CONNECTOR,Female, 2 Pin

Front Left Hazard Lamp, C923

1шт.

28

276426A1

ELEC CONNECTOR,Male, 3 Pin

Left Electric Mirror, C928F

1шт.

29

276424A1

ELEC CONNECTOR,Female, 3 Pin

Left Electric Mirror, DC928M

1шт.
