Артикул
Название
Примечание
Количество
1
87347872
SEAT ASSY.
Cloth, Without Heat
1шт.
Includes Refs. 1 - 30, 34, 35
1шт.
2
373476A1
CUSHION
cloth, without heat
1шт.
3
87347893
SEAT CUSHION
Cloth, Without Heat
1шт.
Includes Ref. 34
1шт.
4
86994155
ASSEMBLY
Backrest
1шт.
Includes Refs. 10, 15
1шт.
5
86994165
SEAT ACCESSORY
Recliner Kit
1шт.
Includes Ref. 22
1шт.
6
NSS
NOT SOLD SEPARAT
PAN, SEAT
1шт.
7
86994157
BRACKET
CONSOLE MOUNT, FRONT
1шт.
8
87347944
SERVICE KIT
Harness, Seat And Suspension
1шт.
9
NSS
NOT SOLD SEPARAT
BRACKET
1шт.
10
87308130
SEAT BACK ADJUST DEV
Lumbar
1шт.
11
87037462
SEAT BACK ADJUST DEV
Lumbar Knob Kit
1шт.
12
NSS
NOT SOLD SEPARAT
SUPPORT, MANUAL HOLDER
1шт.
13
NSS
NOT SOLD SEPARAT
WASHER, 1/8 X 23/64 X 3/64
4шт.
14
NSS
NOT SOLD SEPARAT
RIVET, POP 1/8
4шт.
15
86994172
SERVICE KIT
Manual Holder
1шт.
Includes Refs. 12, 13, 14
1шт.
16
NSS
NOT SOLD SEPARAT
BOLT, SWIVEL, RETAINER
6шт.
17
NSS
NOT SOLD SEPARAT
RETAINER, SWIVEL
1шт.
18
NSS
NOT SOLD SEPARAT
BALL, 1/2
24шт.
19
87347936
SERVICE KIT
SWIVEL
1шт.
Includes Refs. 16, 17, 18
1шт.
20
87347942
SERVICE KIT
SWIVEL CONTROL
1шт.
21
87347941
SERVICE KIT
SLIDE CONTROL
1шт.
22
87416475
KNOB
Recliner Control
1шт.
23
NSS
NOT SOLD SEPARAT
BRACKET
1шт.
24
302016A1
PACKAGE,SERVICE
kit, slide pucks
1шт.
25
87347939
SERVICE KIT
Armrest LH, Cloth, Without Heat
1шт.
25a
87667335
ARMREST
seat, LH
1шт.
26
87347934
LATCH
SLIDE
1шт.
27
87396230
BUSHING
Kit, Console
1шт.
28
86400227
SWITCH,Two Connectors, 90° Terminals
Plunger, SPST
1шт.
29
87347940
ROCKER SWITCH
Seat, Valve Combo
1шт.
30
87347956
SERVICE KIT
SWIVEL
1шт.
34
NSS
NOT SOLD SEPARAT
HARNESS
1шт.
35
NSS
NOT SOLD SEPARAT
HARNESS
1шт.
Выбрано товаров: 39
