Запчасти Case IH TITAN 3520 (02-020[01]) - RADIATOR COMPONENTS, TITAN 3020, TITAN 3520 (01) - ENGINE

1

87311249

RADIATOR

ENGINE

1шт.

2

87271511

PIPE

TOP RADIATOR

1шт.

3

BN324918

FAN

30.5" POLY

1шт.

4

A184546

SPACER

Fan, 60 mm

1шт.

5

87529312

WASHER,11mm ID x 24mm OD x 3mm Thk

4шт.

6

86980410

BOLT,Hex, M10 x 100mm, Cl 8.8

M10 1.5 X 100, 8.8, DOR

4шт.

7

87750942

HOSE CLAMP

NO ABA-12075

8шт.

8

BN324392

RADIATOR HOSE,57.00 mm ID x 110.00 mm, SAE 20R4 Class D1 per SAE J20

Lower Engine

1шт.

9

BN324144

MOUNTING PLATE

Recovery Bottle and Windsheild Washer Bottle

1шт.

10

87481454

BOTTLE

Tank, Coolant Recovery, 5 qt

1шт.

11

86507190

CAP

Coolant Recovery Bottle

1шт.

12

BN324394

RADIATOR HOSE,57.00 mm ID x 110.00 mm, SAE J20, SAE 20R4

Straight Radiator Coupling

2шт.

13

BN324393

RADIATOR HOSE,58.00 mm ID, SAE 20R4 Class D1 per SAE J20

Lower Radiator

1шт.

14

87266634

PIPE

LOWER RADIATOR

1шт.

15

87529315

WASHER,9mm ID x 17mm OD x 2mm Thk

9 x 17 x 2 mm, HDN, DOR

19шт.

16

86980379

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

12шт.

17

9991588

NUT,M8 x 1.25, Cl 8

5шт.

18

86980380

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd

2шт.

19

86637976

CLAMP,19mm, Coat, 8.7mm Bolt Hole, P Type

3шт.

20

344297A1

TANK

de-aeration

1шт.

21

344288A1

MOUNTING PLATE

DEARATION TANK

1шт.

22

A170241

RADIATOR CAP

15 psi

1шт.

23

86986488

BRACKET, SUPPORTING

Mount, Dearation Tank

1шт.

24

87017579

FITTING,3/8" Hose X 1/4" NPTF Beaded

2шт.

25

87267456

WASHER

FAN BLADE

1шт.

26

87267457

HOSE

Barb, 3/8 X 1/8 NPT

1шт.

27

217-1015

ELBOW,1/4" - 18 Female x 1/4" - 18 Male

1шт.

28

87266873

NIPPLE

1/4" NPT x 3.0 SS

1шт.

29

217-1101

HYD CONNECTOR,1/4"-18 NPTF, Female

1шт.

30

86625234

DRAINCOCK/TAP SUPPLY,1/4" NPTF

Valve, 1/4" Weatherhead

1шт.

31

87265544

FUEL HOSE,9.53 mm ID x 1244.60 mm, SAE 30R6, SAE 30R7

3/8" X 49"

1шт.

32

9706921

HOSE CLAMP,12.7mm - 35mm

2шт.

33

214-1704

HOSE CLAMP,#04, 0.25" - 0.62", Type M Worm

7шт.

34

331-512

ANTIFREEZE

mixed 50-50

48шт.

35

342656A1

HOSE

3/4" X 51"

1шт.

36

342658A1

HOSE

5/16" x 67"

1шт.

37

BN313747

FUEL HOSE,0.375" ID x 10.0", SAE 30R6,SAE 30R7

1шт.

38

BN314898

HOSE,0.31" ID x 50.00"

1шт.
