Запчасти Case IH FLX4510 (01-048) - RH CONSOLE TRANSMISSION GROUP (10) - CAB

1

343197A1

BRACKET, SUPPORTING

mount, transmission control

1шт.

2

343193A1

HOUSING

transmission control

1шт.

3

87343600

SCREW,Phil Pan Hd, M5 x 16mm, Cl 4.8, Full Thd

4шт.

4

86986401

SWITCH ASSY

Rotary, 4 Position

1шт.

5

342794A1

KNOB

switch, rotary

1шт.

6

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

2шт.

7

87267356

SOFT TRIM

Ring Transmission Control

1шт.
