0
J948583
CYLINDER HEAD
With Valves
1шт.
0
JR948583
REMAN-CYLINDER HEAD
Head Assembly - Cylinder, With Valves, Remanufactured (For Service Order J948583)
1шт.
0
JC948583
CORE-CYLINDER HEAD
Return Part Number, Cylinder Head With Valves
1шт.
1
NSS
NOT SOLD SEPARAT
Head Assembly - Cylinder, Without Valves
1шт.
2
A77552
PLUG
Expansion, 29/64" Diameter
6шт.
3
J900955
PLUG
Expansion, 10 MM OD
1шт.
4
A77590
PLUG
Expansion, 28.7 mm od
2шт.
5
J907555
PLUG
Rocker Arm Shaft
1шт.
6
J920706
PLUG
Expansion, 22 MM OD
17шт.
7
J940152
INSERT
Intake Valve
12шт.
8
J940153
INSERT
Exhaust Valve
12шт.
9
41-1624
PLUG,Cup, 1 1/2", Stainless
2шт.
10
J948102
VALVE GUIDE
Stem
24шт.
11
CASJ900250
RETAINER
Keeper - Valve
48шт.
12
J942588
STD INLET VALVE
STD ENGINE INLET VALVE
12шт.
13
J942589
STD EXHAUST VALVE
STD ENGINE EXHAUST VALVE
12шт.
14
J991267
SEAL
Valve Stem
24шт.
15
J944452
RETAINER
Valve Spring
24шт.
16
J944711
VALVE SPRING
24шт.
17
J678923
PLUG,M10 x 1
Hex Socket, 10 MM
1шт.
18
86625087
O-RING,1.6mm Thk x 8.1mm ID, Cl 7, 75 Duro
1шт.
19
J943366
CYLINDER HEAD GASKET,2.11mm Thk
Standard
1шт.
20
87344126
BOLT
M14 x 160
26шт.
21
J943445
CROSSBAR
Crosshead
12шт.
22
J944174
PUSH ROD
12шт.
23
J943933
SCREW,Hex Flg, M10 x 1.5 x 68mm, Cl 10.9
Hex Flange Head, 10-1.5 X 68 MM, Class 10.9
12шт.
24
J941137
SHAFT
Rocker Arm
12шт.
25
J941140
SUPPORT
Rocker Arm
6шт.
25a
J942748
ROCKER ARM
Intake
6шт.
Consists Of Refs. 26 - 31
1шт.
25b
J942749
ROCKER ARM
Exhaust
6шт.
Consists Of Refs. 26 - 30, 32
1шт.
26
NSS
NOT SOLD SEPARAT
Retainer, Socket
1шт.
27
NSS
NOT SOLD SEPARAT
Socket - Rocker Arm
1шт.
28
A77902
NUT
Special, 3/8"-24, Heavy, Type 8
1шт.
29
J991067
ADJUSTMENT SCREW,3/8" - 24 x 27.58mm
Rocker Arm Adjusting
1шт.
30
NSS
NOT SOLD SEPARAT
Ball - Rocker Arm
1шт.
31
NSS
NOT SOLD SEPARAT
Arm - Rocker, Intake
1шт.
32
NSS
NOT SOLD SEPARAT
Arm - Rocker, Exhaust
1шт.
33
J945866
TAPPET
Valve
12шт.
34
263136
MAGNETIC PLUG,Sq. Soc, 3/4"-14 NPTF
PLUG, MAGNETIC
1шт.
35
444704
PLUG,Hex Soc, 1/2"-14
1шт.
36
9617020
PLUG,1/4" - 18 x 0.48"
1шт.
Not Shown
1шт.
37
J943670
FITTING
Orifice
1шт.
