Запчасти Case IH FLX3300B (04-001) - FRONT AXLE ASSEMBLY Frame & Suspension

1

232-46410

LOCK NUT

5/8-18, TLN, CL 8

8шт.

2

428-1036

SCREW

5/8-18 X 2.25, HH, G8

8шт.

3

BN2303412

LOCK WASHER

3/8

8шт.

4

BN321318

FLANGED BEARING

Flanged MSF-39

2шт.

5

88011

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

8шт.

6

BN7136046

BEARING COVER

Front Axle Bearing

2шт.

7

BN7136030

CENTER AXLE

Front Axle Assembly - 3/4 Stud, See Fig 04-002

1шт.
