Артикул
Название
Примечание
Количество
JR918986
REMAN-CRANKSHAFT
Assembly, Engine, Remanufactured, Component Parts Shown On This Page Do Not Apply To The Remanufactured Assembly
1шт.
JC918986
CORE-CRANKSHAFT
Return Number - Use This Part Number To Return Crankshaft Core For Credit When Using A Remanufactured Assembly
1шт.
1
NSS
NOT SOLD SEPARAT
Crankshaft
1шт.
4
NSS
NOT SOLD SEPARAT
Seal - Oil, Front (Order Ref. 14, A77790)
1шт.
5
J943660
PULLEY
Fan
1шт.
5a
J914119
DAMPER
Vibration
1шт.
6
J914118
FLANGE BOLT,Hex, M14 x 1.5 x 60mm, Cl 12.9
Hex Flange, Special
4шт.
7
NSS
NOT SOLD SEPARAT
Seal - Oil, Rear (Order Ref. 24, J934486)
1шт.
10
87015915
BOLT,Hvy Hex, M6 x 15mm, Cl 8.8, Full Thd
8шт.
11
J945931
BEARING SET
Main, Upper And Lower Set, 0.25 mm Undersize
6шт.
11
J945932
BEARING SET
Main, Upper And Lower Set, 0.50 mm Undersize
6шт.
11
J945933
BEARING SET
Main, Upper And Lower Set, 0.75 mm Undersize
6шт.
11
J945734
Main, Upper And Lower Set, 1.00 MM Undersize
6шт.
12
J945922
THRUST BEARING
Main Thrust, Upper and Lower Set, 0.25 mm Undersize
1шт.
12
J945923
THRUST BEARING
Main Thrust, Upper and Lower Set, 0.50 mm Undersize
1шт.
12
J945924
THRUST BEARING
Main Thrust, Upper and Lower Set, 0.75 mm Undersize
1шт.
12
J945925
THRUST BEARING
Main Thrust, Upper and Lower Set, 1.0 mm Undersize
1шт.
12
J945926
THRUST BEARING
Main Thrust, Upper and Lower Set, Standard JourNal Diameter, 0.25 mm Oversize Thrust Width
1шт.
12
J945927
THRUST BEARING
Main Thrust, Upper and Lower Set, Standard Journal Diameter, 0.50 mm Oversize Thrust Width
1шт.
12
J945928
THRUST BEARING
Main Thrust, Upper and Lower Set, 0.50 mm Undersize Journal Diameter, 0.50 mm Oversize Thrust Width
1шт.
13
J918113
SHIELD,74.73mm ID x 91.7mm OD x 6mm Thk
Dust (Order Ref. 14, A77790)
1шт.
15
NSS
NOT SOLD SEPARAT
Seal - Oil, Front
1шт.
16
NSS
NOT SOLD SEPARAT
Tool - Installation
1шт.
17
NSS
NOT SOLD SEPARAT
Tool - Installation
1шт.
18
J918113
SHIELD,74.73mm ID x 91.7mm OD x 6mm Thk
Dust
1шт.
19
A77808
SERVICE KIT
Wear Sleeve, Crankshaft Front
1шт.
20
NSS
NOT SOLD SEPARAT
Sleeve - Wear
1шт.
21
NSS
NOT SOLD SEPARAT
Tool - Installation
1шт.
22
NSS
NOT SOLD SEPARAT
Seal - Oil, Front
1шт.
23
J924987
SHIELD,77.14mm ID x 89.38mm OD x 6.35mm Thk
Dust
1шт.
25
NSS
NOT SOLD SEPARAT
Seal - Oil, Rear
1шт.
26
NSS
NOT SOLD SEPARAT
Tool - Installation
1шт.
Not Shown
1шт.
26a
NSS
NOT SOLD SEPARAT
Tool - Installation
1шт.
Not Shown
1шт.
27
A77810
SERVICE KIT
Wear Sleeve, Crankshaft Rear
1шт.
28
NSS
NOT SOLD SEPARAT
Sleeve - Wear
1шт.
29
NSS
NOT SOLD SEPARAT
Seal - Oil, Rear
1шт.
Выбрано товаров: 47
