Запчасти Case IH 4330 (08-001[02]) - MAIN ELECTRICAL HARNESSES (06) - ELECTRICAL

1

BN302156

WIRE HARNESS

Vehicle, Allison

1шт.

2

BN303517

WIRE HARNESS

Selector Harness, Allison

1шт.

3

BN302158

WIRE HARNESS

Trans, ECU

1шт.

5

BN302159

WIRE HARNESS

TRANS, COMP

1шт.

7

BN311845

WIRE HARNESS

Titan Main Cab

1шт.

8

BN303956

WIRE HARNESS

Engine Interface

1шт.

10

NSS

NOT SOLD SEPARAT

Electrical Panel Assembly

1шт.

See Fig. 08-002

1шт.

11

NSS

NOT SOLD SEPARAT

Left Dash Assembly

1шт.

See Fig. 01-001

1шт.

12

BN303014

WIRE HARNESS

LTS & RELO

1шт.

13

BN303224

WIRE HARNESS

Hydraulic Oil Sensors

1шт.

14

BN303015

WIRE HARNESS

Lts & RELAO

1шт.

15

BN8207006

WIRE HARNESS

Main Light

1шт.

16

BN8207047

WIRE HARNESS

B3F/B4M/C1M Dash

1шт.

17

BN8207045

WIRE HARNESS

C1F Right Console

1шт.

18

BN8207085

WIRE HARNESS

Foam Marker

1шт.

20

BN8207014

Headlights

1шт.

21

BN8207076

WIRE HARNESS

Windshield Washer

1шт.
