Запчасти Case IH 4330 (03-002) - DRIVELINE (03) - TRANSMISSION

1

BN2296454

FENDER ASSY.

913356(67)

1шт.

2

BN2296469

DRIVEN SHAFT

905343 (54.37)

1шт.

3

BN7146366

MOUNTING PLATE

Driveline Bearing

1шт.

6

BN1913404C

HH 3/8-16 X 3-1/4 N

4шт.

7

87529233

WASHER,0.41" ID x 0.81" OD x 0.09" Thk

3/8"

4шт.

8

BN1470404C

LOCK NUT

NC 3/8-16 Flex Lock

4шт.

9

BN2292588

YOKE

End 6-4-5131X (1710)

1шт.

10

BN1470406C

LOCK NUT

NC 1/2-13 Flex Lock

2шт.

11

BN1913337C

BOLT

HH 1/2-13 X 1-1/2 N

2шт.

12

BN2303146

WASHER

Flat 1/2

2шт.

13

BN7146503

STRIP

Spacer CAT (Front)

1шт.

14

BN7146282

PLATE

Driveline Mount

1шт.

17

BN1913346C

BOLT

HH 7/16-14 X 1-3/4

4шт.

18

BN2303145

WASHER

Flat 7/16

8шт.

19

BN1470405C

NUT

NC 7/16-14 Flex Lock

4шт.
