Запчасти Case IH 4330 (03-001[01]) - TRANSMISSION GROUP (03) - TRANSMISSION

1

BN1470408C

LOCK NUT

NC 5/8-11 Flex Lock

4шт.

2

9627896

BOLT,Hex, 5/8" - 11 x 1 3/4", Gr 5

4шт.

3

BN2293131

FITTING

0503-12-16

1шт.

4

BN2296633

FITTING

2061-12-16

1шт.

5

80679

LOCK WASHER,1/20.507 CST ZND

2шт.

6

BN302159

WIRE HARNESS

Transmission, Interface

1шт.

7

BN304256

TRANSMISSION

Allsion MD3060

1шт.

7a

2402071-002

FILTER

Oil

1шт.

Service Parts For Ref. 7

1шт.

7b

BN2402071-003

BALANCER

29503328

3шт.

Service Parts For Ref. 7

1шт.

7c

BN2402071-004

PLATE

29503696

1шт.

Service Parts For Ref. 7

1шт.

7d

BN2402071-005

DIPSTICK

Transmission Fluid

1шт.

Service Parts For Ref. 7

1шт.

7e

BN2402071-006

PLATE

1шт.

Service Parts For Ref. 7

1шт.

7f

BN2402071-007

Ring 29503695

1шт.

Service Parts For Ref. 7

1шт.

7g

BN2402071-008

RING GEAR

Assembly

1шт.

Service Parts For Ref. 7

1шт.

7h

BN2402071-009

SENSOR

Throttle Position

1шт.

Service Parts For Ref. 7

1шт.

7j

BN2402071-010

MOUNTING PLATE

TPS Bracket

1шт.

Service Parts For Ref. 7

1шт.

7k

BN2402071-011

WIRE HARNESS

VIM 29506606

1шт.

Service Parts For Ref. 7

1шт.

7l

BN2402071-012

WIRE HARNESS

VIM 29518142

1шт.

Service Parts For Ref. 7

1шт.

7m

BN2402071-013

WIRE HARNESS

29518270

1шт.

Service Parts For Ref. 7

1шт.

7n

BN2402071-014

MODULE

Vehicle Interface

1шт.

Service Parts For Ref. 7

1шт.

7p

BN2402071-015

Electronic Control Unit

1шт.

Service Parts For Ref. 7

1шт.

7q

BN2402071-016

REPAIR KIT

Adaptation 295/330

1шт.

Service Parts For Ref. 7

1шт.

Includes -003, -004, -006, -008

1шт.

8

BN7146462

MOUNT

MD Harness Support

1шт.
