Запчасти Case IH FLX810 (13-001) - FLEX-AIR® CONTROL PANEL - 4600 RAVEN (06) - ELECTRICAL

1

377999A1

CONSOLE

console control

1шт.

2

BN324088

DECAL

Fan

1шт.

3

BN324090

Foam

1шт.

4

BN321912

SWITCH

assembly, foam activate

1шт.

5

BN324091

DECAL

Boom Position

1шт.

6

BN322626

PLUG

Panel, NGR

7шт.

7

BN321913

SWITCH

boom fold LH

1шт.

8

BN321915

SWITCH

Boom Fold RH

1шт.

9

BN324370

SWITCH

Assembly Fan, On/Off

1шт.

10

BN324369

SWITCH

Assembly Fan, Set

1шт.

11

BN324087

DECAL

Decel

1шт.

12

BN324089

DECAL

Product

1шт.

13

BN24129

SWITCH

On-None-On Dpdt

3шт.

14

BN324092

DECAL

Gate

1шт.

15

118780A1

KNOB

Console Control

1шт.

16

128833A2

GUIDE

Propulsion Control Lever

1шт.

17

BN324151

SWITCH

Cruise Control, Set

1шт.

18

BN324396

SWITCH

Boom Section

1шт.

19

BN324411

SWITCH

Auger, On/Off

1шт.

20

BN324404

SWITCH

Bin Gate

2шт.

21

BN324999

SWITCH

Main Power

1шт.

22

86986401

SWITCH ASSY

Rotary, 4 Position

1шт.

23

342794A1

KNOB

switch, rotary

1шт.

24

282056A1

PLUG

double d

1шт.

25

BN321916

SWITCH

Sparge Pressure

1шт.
