Запчасти Case IH FLX810 (04-020) - BOOM FOLD PARTS, MID, 70’ Boom Group

1

BN10465

NIPPLE, LUBE,1/4"-28 st

NIPPLE

12шт.

2

BN35642

SUPPORT

Hinge, Mid

2шт.

3

BN35722

PIN

Boom, Inner

2шт.

4

BN35882

SUPPORT

Hinge, Mid, RH

1шт.

5

BN35883

SUPPORT

Hinge, Mid, LH

1шт.

6

BN35983

SPACER

Door Hinge, 7 GA

6шт.

6

BN35984

SPACER

Door Hinge, 10 GA

3шт.

6

BN35985

SPACER

Door Hinge, 12 GA

4шт.

7

342683A1

SPACER

boom, 14 GA

3шт.

7

BN35990

SPACER

Boom, 7 GA

3шт.

7

BN35991

SPACER

Boom, 10 GA

3шт.

7

BN35992

SPACER

Boom, 12 GA

3шт.

8

BN50071

NUT,1/2"-13, Stainless

2шт.

9

BN50082

JAM NUT

5/8-11 Hex Jam

2шт.

11

BN50156

LOCK WASHER

5/8 Spring Lock

4шт.

12

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

13

87337

BOLT,Hex, 3/4" - 10 x 3", Gr 5

4шт.

14

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

4шт.

15

BN50600

COTTER PIN

3/16" X 1 & 1/2"

2шт.

16

BN50688

BOLT,Hex, 1/4" - 20 x 1-1/4", SST

1/4"-20 X 1-1/4", Stainless Steel

14шт.

17

280505

BOLT,Hex, 3/8"-16 x 7 1/2", G5

10шт.

18

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

12шт.

19

280375

NUT,3/4"-10, GC

4шт.

20

BN55347

BOLT

1/2-13 X 3, Stainless Steel, Tap

2шт.

21

BN55359

LOCK NUT,1/4"-20, SS

14шт.

22

BN305447

SCREW,5/8" - 11 x 3", Gr 8

5/8-11 x 3, HHFT, G8

2шт.

23

343757A1

SUPPORT

cradle, 70' boom

2шт.

24

BN65724

HINGE

Boom, MID, RH

1шт.

25

BN65725

HINGE

Boom, MID, LH

1шт.

26

87266446

HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 406.4mm Stroke

Hydraulic, 2.5 x 16 x 1.25, Complete

2шт.

See Fig. 07-005

1шт.

26

87266446R

REMAN-HYD CYLINDER

FLX810 FLEX-AIR APPLICATOR, MID, 70’, Hydraulic, 2.5 x 16 x 1.25, Complete (10/03-8/09)

2шт.

26

87266446C

CORE-HYD CYLINDER

Return Number

2шт.

27

BN69951

CAP

Grease

12шт.
