Запчасти Case IH FLEX-AIR (04-003) - REAR BOOM GROUP Boom Group

1

BN5412

Pin - Locking MW

1шт.

2

BN15497

CLAMP,76.2mm - 82.55mm

3 1/4", SS, T-Bolt

4шт.

3

BN31444

PIN, ROLL

1/4 x 1 1/2

1шт.

4

BN31937

SPRING

Compression, .905 x .765 2

1шт.

5

BN35496

Airway, RH, Rear

1шт.

6

BN35497

Airway, LH, Rear

1шт.

7

BN35641

Cradle - Hinge, Rear

2шт.

8

BN35652

Cradle Rear, RH

1шт.

9

BN35653

Rear, LH

1шт.

10

BN35877

Support, Hinge, Rear, RH

1шт.

11

BN35878

Support, Hinge, Rear, LH

1шт.

12

BN35913

Venturi - Rear, RH

1шт.

13

BN35914

Venturi - Rear, LH

1шт.

14

BN68492

U-BOLT

3/8 - 16 UNC X 3, SS

4шт.

15

344018A1

DEFLECTOR

RH

1шт.

16

BN65386

DEFLECTOR

LH

1шт.

17

344019A1

DEFLECTOR

Rear

2шт.

18

BN65722

Hinge, Boom, Rear, RH

1шт.

19

BN65723

Hinge, Boom, Rear, LH

1шт.

20

BN67353

Platform, Flex - Air

1шт.

21

BN67363

Ladder, Platform

1шт.

22

BN67409

Tube, Rear Mount

2шт.

23

BN67472

Platform

2шт.

24

BN67473

Safety - Walk - Flextread, 6 X 83.5

1шт.

25

BN67474

Safety - Walk - Flextread, 6 X 30.5

2шт.

26

BN67511

9/16 ID X 3/4, Nylon

2шт.

27

BN50157

WASHER

3/4, G5

1шт.

28

BN50284

BOLT

1/2-13 X 1.5, HH, PL

2шт.

29

86992215

LOCK NUT,1/2"-13, GC

2шт.

30

BN50061

LOCK NUT

3/8"-16, UNC, Whiz

4шт.

31

BN50367

BOLT

3/8"-16 x 1", G5

4шт.

32

BN50155

WASHER,17.48mm ID x 44.45mm OD x 3.05mm Thk

5/8", G5

4шт.

33

BN68086

CAP

Round, Rubber, .25 ID

4шт.

34

BN8171104

Frame Extension 48"

1шт.
