(78.110.03.DA) - CENTER CO-AP BRACE

Запчасти Case IH 810 (78.110.03.DA) - CENTER CO-AP BRACE (78) - SPRAYING

Схема запчастей Case IH 810 - (78.110.03.DA) - CENTER CO-AP BRACE (78) - SPRAYING
6
home
4
3
1
5
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84185176

BRACKET

Center Co-Ap Support, Complete, Includes Ref 2 - 6

1шт.

2

84188692

BRACKET

Rear Co-Ap Support

1шт.

3

84187133

BRACKET

Front Co-Ap Support

1шт.

4

87342769

BOLT

3/8-16 X 1-1/2, G5, DOR

4шт.

5

87529237

WASHER,0.41" ID x 0.81" OD x 0.07" Thk

0.406 x 0.812 x 0.065, HTS, DOR, HDN

4шт.

6

87343970

NUT,3/8"-16, G8, DOR

4шт.
