(55.640.02) - NODE GROUP, DOUBLE BIN, WITHOUT AUGERS, VIPER PRO

Запчасти Case IH 810 (55.640.02) - NODE GROUP, DOUBLE BIN, WITHOUT AUGERS, VIPER PRO (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 810 - (55.640.02) - NODE GROUP, DOUBLE BIN, WITHOUT AUGERS, VIPER PRO (55) - ELECTRICAL SYSTEMS
1
4
3
home
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47514868

CONTROL BLOCK

Can, Co-Application Bin Without Auger

1шт.

2

BN50258

BOLT,3/8"-16 X 1.25", Stainless

6шт.

3

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

6шт.

4

87267288

CONTROL

Can, Main Control

1шт.

5

BN50146

WASHER,3/8", Stainless

6шт.
