Запчасти Case IH 810 (02-045) - 6" AUGER HYDRAULIC TUBES GROUP, DOUBLE & TRIPLE BIN, 37 & 50 CU. FT. Bin Group

1

BN300395

BOLT,1/4"-20 x 1-3/4", Stainless Steel

3шт.

2

BN306977

TUBE

4 GATE

1шт.

3

BN306978

TUBE

4 GATE, ROD

1шт.

4

BN307911

CLAMP

DUAL, 3/8 TUBE

1шт.

5

BN307915

CLAMP

SINGLE, 3/8 TUBE

2шт.

6

BN309486

PLATE

TOP, DUAL, SIZE 1

1шт.

7

BN309487

PLATE

TOP, SINGLE, SIZE 0

2шт.

8

BN50138

WASHER,1/4", SS

1шт.

9

BN55359

LOCK NUT,1/4"-20, SS

3шт.

10

BN309848

SCREW,Hex, 5/16" - 18 x 3", SST

2шт.

11

BN309849

CLAMP

DUAL, 1.25 TUBE

2шт.

12

BN309850

PLATE

TOP, DUAL, SIZE 5

2шт.

13

BN55361

NUT,5/16"-18, Nylon, Stainless

2шт.

14

BN305412

O-RING

FOR 6 FFOR

6шт.
