Запчасти Case IH 810 (02-039) - VALVE BOX Bin Group

1

BN307047

PIN

3/8, WITH SHOULDER

4шт.

2

87268848

BOX

Valve - 438A

1шт.

3

BN306268

COVER

ACCESS, VALVE BOX

1шт.

4

BN310283

PIN

3/8, WITH .75 SHOULDER

2шт.

5

BN50138

WASHER,1/4", SS

2шт.

7

BN50146

WASHER,3/8", Stainless

16шт.

8

BN50212

BOLT,1/4"-20 x 3/4", Stainless Steel

2шт.

9

BN50258

BOLT,3/8"-16 X 1.25", Stainless

4шт.

10

BN50254

BOLT,3/8"-16 x 1", Stainless

5шт.

11

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

16шт.

12

BN52033

BOLT,1/4"-20 X 5/8", Stainless Steel

4шт.

13

BN55359

LOCK NUT,1/4"-20, SS

6шт.

15

BN65808

LATCH

ADJUSTABLE DRAW

2шт.

17

BN67852

COVER

W/M, SIDE, R.H.

1шт.

18

BN67855

COVER

W/M, SIDE, L.H.

1шт.

19

BN67857

ANGLE

MOUNT, SIDE COVER

2шт.

20

BN71007

CLIP,3/16" Hairpin

Hairpin, 3/16" #8

6шт.

21

87265990

PLUG

BUTTON, FLUSH TYPE

1шт.

22

87271165

CABLE,713mm L

Breakaway, 28"

1шт.

23

BN311038

NUT

5/16-18 X 2, HH, SS

1шт.

24

BN23452

WASHER,13/32" x 1.25 " OD x 12 GA, SS

12шт.

25

87268865

RETAINER COLLAR

HINGE, DOOR

2шт.

26

BN50232

BOLT,5/16"-18 x 1.00", Stainless Steel

2шт.
