1
BN323213
HYDRAULIC VALVE
Block, Single
1шт.
See Fig. 07-010
1шт.
2
BN65718
HYDRAULIC MOTOR
Valve Box Group
1шт.
See Fig. 07-018
1шт.
3
BN50138
WASHER,1/4", SS
6шт.
4
BN50144
LOCK WASHER
5/16, LW, SS
4шт.
5
BN50212
BOLT,1/4"-20 x 3/4", Stainless Steel
6шт.
6
BN50476
BOLT,5/16"-18 x 0.75", Stainless
8шт.
7
BN55359
LOCK NUT,1/4"-20, SS
6шт.
8
86986497
HYDRAULIC VALVE
Control 7 Bank CR
1шт.
See Fig. 07-011
1шт.
9
BN67858
MOUNTING PARTS
Waterman Valve
2шт.
10
BN67859
COVER
Waterman Valve
1шт.
11
BN313449
COVER
Valve Box Side
1шт.
12
BN55361
NUT,5/16"-18, Nylon, Stainless
4шт.
