Запчасти Case IH 438 (06-004) - PUMP GROUP, FLEX, 4330 Hydraulic Plumbing

1

280980

NUT,7/16"-14, GC

4шт.

2

BN300367

BOLT

1/2 - 20 X 1, HH, G8

4шт.

3

BN300407

FLANGE NUT

Flg, 1/2"-13, G8

8шт.

4

86986504

PUMP

Pressure Comp-60 cc

1шт.

See Fig. 07-006

1шт.

5

BN309564

PUMP

75Cc, 90 Series, Auxiliary C

1шт.

See Fig. 07-009

1шт.

6

86624188

WASHER,0.53" ID x 1.06" OD x 0.13" Thk

16шт.

7

84155893

VALVE POPPET

48 SEC, Motorized Relief

1шт.

8

BN310240

SPACER

Remote Servo

1шт.

9

BN314397

GUARD

4330

1шт.

10

BN311273

BRACKET, SUPPORTING

Mount, Pump, Front, 4330

1шт.

11

BN311274

MOUNTING PLATE

Mount, Pump, Rear, 4330

1шт.

12

NSS

NOT SOLD SEPARAT

Driveline, 4 Whl W/ CDC

1шт.

See Fig. 08-001

1шт.

13

BN304157

GEARBOX

RH W/1.5" 10 Spline

1шт.

13

BN304157R

REMAN-PTO GEARBOX A.

438 FLEX-AIR APPLICATOR, RH (3/03-10/03)

1шт.

13

BN304157C

CORE-PTO GEARBOX A.

Return Number

1шт.

14

BN35690

FILTER

Fairy - Arlon, HI P

1шт.

See Fig. 07-016

1шт.

16

BN50378

BOLT

1/2 - 13 X 2, HH, 8, BK

4шт.

17

413-718

BOLT,Hex, 7/16" - 14 x 1-1/8", Gr 5

4шт.

18

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

8шт.

19

BN55235

BOLT,Hex, 1/2"-13 x 1 1/2", G8, Full Thd

10шт.

20

BN55359

LOCK NUT,1/4"-20, SS

2шт.

21

BN67050

BOLT,1/4"-20 X 3.00", Stainless Steel

2шт.

22

BN67505

MANIFOLD

Meter Filter

1шт.

23

BN68212

BOLT

3/8 - 16 X 4, HH, SS

2шт.

24

BN309664

FILTER

Hydraulic, Oil, Medium Pressure

1шт.

25

BN310239

MOUNTING PLATE

Remote Filter

1шт.

26

BN50250

BOLT,3/8"-16 x 3/4", Stainless Steel

4шт.

27

BN50254

BOLT,3/8"-16 x 1", Stainless

2шт.
