Запчасти Case IH 438 (08-001) - BOOM FOLD PARTS, MID Boom Group

1

BN10465

NIPPLE, LUBE,1/4"-28 st

NIPPLE

12шт.

2

BN35642

SUPPORT

Hinge, Mid

2шт.

3

BN35722

PIN

Boom, Inner

2шт.

4

BN35882

SUPPORT

Hinge, Mid, RH

1шт.

5

BN35883

SUPPORT

Hinge, Mid, LH

1шт.

6

BN35983

SPACER

Door Hinge, 7 GA

6шт.

6

BN35984

SPACER

Door Hinge, 10 GA

3шт.

Associated Part Of Plug, Hollow Hex, P/N BN303868

1шт.

6

BN35985

SPACER

Door Hinge, 12 GA

4шт.

Indicates Old Part Number Or Can Order Newer Part Number Listed Above

1шт.

7

BN35990

SPACER

Boom, 7 GA

1шт.

7

BN35991

SPACER

Boom, 10 GA

1шт.

Indicates Old Part Number Or Can Order Newer Part Number Listed Above

1шт.

7

BN35992

SPACER

Boom, 12 GA

1шт.

Indicates Old Part Number Or Can Order Newer Part Number Listed Above

1шт.

8

BN50071

NUT,1/2"-13, Stainless

2шт.

9

BN50082

JAM NUT

5/8-11 Hex Jam

2шт.

10

BN50086

NUT

3/4-10, HH, G5

4шт.

11

BN50156

LOCK WASHER

5/8 Spring Lock

4шт.

12

BN50367

BOLT

3/8"-16 x 1", G5

2шт.

13

BN50333

BOLT

3/4-10 X 3, HH, G5

4шт.

14

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

4шт.

15

BN50600

COTTER PIN

3/16" X 1&1/2"

2шт.

16

BN50688

BOLT,Hex, 1/4" - 20 x 1-1/4", SST

1/4"-20 X 1-1/4", Stainless Steel

14шт.

17

300404

NUT

SPARE PART 3/8-16 X 7.5, HH, G5

10шт.

18

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

14шт.

19

BN50857

3/8-16 X 6, HH, G5

2шт.

20

BN50969

NUT

3/4-10, NLN, G5

4шт.

21

BN53802

WASHER

Beveled, 1/2"

2шт.

22

BN55347

BOLT

1/2-13 X 3, Stainless Steel, Tap

2шт.

23

BN55359

LOCK NUT,1/4"-20, SS

14шт.

24

BN305447

SCREW,5/8" - 11 x 3", Gr 8

5/8-11 X 3, HHFT, G8

2шт.

25

BN65238

SUPPORT

Cradle, Mid, LH

1шт.

26

BN65239

SUPPORT

Cradle, Mid, RH

1шт.

27

BN65724

HINGE

Boom, Mid, RH

1шт.

28

BN65725

HINGE

Boom, Mid, LH

1шт.

29

NSS

NOT SOLD SEPARAT

Cylinder, 2.5 X 16, SAE Ports

2шт.

See Fig. 12-004

1шт.

30

BN69951

CAP

Grease

12шт.
