Запчасти Case IH 437 (04-006) - MID BOOM GROUP Boom Group

1

BN15497

CLAMP,76.2mm - 82.55mm

3 1/4", SS, T-Bolt

4шт.

2

84185931

COUPLING

Pneumatic, 3"

4шт.

3

BN35508

Airway, RH, Mid

1шт.

4

BN35509

Airway, LH, Mid

1шт.

5

BN35642

SUPPORT

Hinge, Mid

2шт.

6

BN35715

TUBE

Round - 3.00 OD X 150.00

2шт.

7

BN35717

TUBE

3.00 OD X 100.00

2шт.

8

BN35718

SUPPORT

Rear Tubes

4шт.

9

BN35882

SUPPORT

Hinge, Mid, RH

1шт.

10

BN35883

SUPPORT

Hinge, Mid, LH

1шт.

11

BN35915

VENTURI

Mid, RH

1шт.

12

BN35916

VENTURI

Mid, LH

1шт.

13

BN65238

SUPPORT

Mid, LH

1шт.

14

BN65239

SUPPORT

Mid, RH

1шт.

16

344019A1

DEFLECTOR

Rear

4шт.

17

BN65388

TUBE

45 X 14.75

2шт.

18

BN65389

TUBE

45 X 40.00

2шт.

19

BN65724

HINGE

Boom, Mid, RH

1шт.

20

BN65725

HINGE

Boom, Mid, LH

1шт.

21

BN68086

CAP

Round, Rubber, .25 ID x 1.00

4шт.

22

BN68398

TUBE

Mid, RH

1шт.

23

BN68399

TUBE

Mid, LH

1шт.

24

BN50593

BOLT,1/2"-13 x 1-1/2", Stainless Steel

4шт.

25

BN50595

WASHER,1/2", Stainless

4шт.

26

BN55363

LOCK NUT,1/2"-13, Nylon, Stainless

4шт.

27

BN8171009

Frame EXT (18")-Titan

1шт.
