Артикул
Название
Примечание
Количество
1
484220R91
FRAME ASSY, main
1шт.
18707R1
CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2
BOLT, 1/2-13 x 1 C-Z sq-nk crg
8шт.
17433R1
HARDWARE,Hex, 1/2" - 13 x 1", Gr 2
BOLT, 1/2-13 x 1 C-Z hex-hd mach
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
10шт.
120384
WASHER,1/2"
LOCK, 1/2"
10шт.
18822R1
BOLT,Hex, 5/8"-11 x 1 1/2", G2, Full Thd
5/8-11 x 1-1/2 C-Z hex-hd mach
4шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
4шт.
2
472416R2
HOUSING
auger feed
4шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd
16шт.
120376
NUT,5/16"-18, G5
16шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
16шт.
3
487632R2
BAR
auger feed
2шт.
21650R1
LOCK PIN,5/16" x 2 1/2", Slotted
Pin, 5/16" x 2 1/2", Slotted
2шт.
187988
COTTER PIN,3/16" x 1 1/4"
PIN, SPLIT (COTTER), 3/16" x 1 1/4"
12шт.
4
472415R1
SPACER
COUPLING, auger
2шт.
89375H
CLEVIS PIN
PIN, 1/4 x 1-19/32 rod end
2шт.
112726
COTTER PIN,1/16" x 1/2"
PIN, SPLIT (COTTER), 1/16" x 1/2"
2шт.
520177R1
PIN
quick attachable cotter
2шт.
5
479217R91
HOPPER ASSY
2шт.
134238R1
WASHER
11/32 x 1 x 16 ga C-Z
16шт.
432438
PLUG, hopper button
2шт.
624456R1
CLIP, lid spring
4шт.
6
472429R1
BAR
PAD, hopper reinforcing
4шт.
7
472401R11
LID ASSY, hopper
2шт.
12235R1
PIN, 1/8 x 3/8 C-Z cotter 1/8" x 5/8"
4шт.
8
479124R1
VALVE SPRING
SPRING, hopper hold-down
4шт.
9
472417R1
BEARING
auger
4шт.
10
472400R2
DIVIDER, fertilizer hopper center, 1 per hopper
1шт.
11
484228R1
BAR, tie hopper strap
1шт.
Выбрано товаров: 30
